The META POWER TR is designed for the ride. With 140mm of travel it's easy to tame and is forgiving to the rider. Dynamic and playful, it ensures effective pedalling thanks to excellent geometry. The straightened seat tube and long front-end ideally positions the rider between the two wheel axles. The 29-inch wheels allow you to tackle the most technical climbs. This is the bike for those who like long rides and enjoying letting go of the brakes on the downhill.
META POWER TR SIGNATURE
This Keswick Green finish of our SIGNATURE model matches perfectly with the Kashima coating of its FOX components.
On this version of our META POWER TR, you'll find the best combo of components on the market from the likes of FOX, SHIMANO and DT SWISS. The new SHIMANO EP8 motor and 630Wh battery significantly increase the POWER capabilities. It features the new FOX 36 Factory 150mm fork with 36mm diameter stanchions as well as the Float DPX2 shock on the back. This combo is the brand's finest performance suspension set-up in the e-bike category. Numerous hydraulic adjustment settings will satisfy the most demanding riders. It also features the SHIMANO XT 12-speed drivetrain and SHIMANO XT 4-piston brakes. The Japanese brand is known for their reliability, easy maintenance and ultra-performance. We also opted for short 160mm cranks to make pedalling up steeper trails easier thanks to more ground clearance. Finally, there's the new DT SWISS HX1700 e-bike specific wheels which bring performance, strength and reliability.
*Please note that bike specs are subject to change without prior notice.
Bicycle type
E-bike Trail 29"
Frame material
AL-6061 + AL-6066
Frame weight
4,1 kg / 9.03 lb - With plastic accessories.
Rear travel
140 mm
Shock length/stroke
210 x 55 mm
Piggy back shock compatible
Yes
Shock bushings
20 x 10 mm front
Recommended/max. fork height
566 mm / 576 mm
Headset dimension
Tapered
Headset type
ZS56 / ZS66
Maximum tyre dimension (etrto)
65 mm - 622
Disc brake standard
Postmount
Rear rotor max. size
220 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
SHIMANO EP800
ISCG
Yes (SHIMANO Standard)
Rear hub compatibility
12 x 148 mm, Maxle standard
Frame
2021 Meta Power TR, 140 mm travel
29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
System
SHIMANO DU-EP800
250 W, 85 Nm
Battery
SHIMANO BT-E8036
630Wh
Display
SHIMANO SC-EM800
LCD colored display featuring: Clock, Assist mode display, Battery charge level, Current Speed, Maximum speed, Average speed, Trip distance, Trip time, Estimated range, Range overview, Cadence, Human output power (as scale indicator), Calorie setting, Maintenance alert, Bluetooth LE connection (for E-Tube Project communication)
Shock
FOX DPX2 Factory
210 x 55 mm, LSC, LSR, 3-position adjustment
Fork
FOX 36 Factory E-Bike, 150 mm travel
29", Grip 2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 44 mm offset, oversized crown
Headset
ACROS ZS56 / ZS66
Alloy cups, sealed bearings
Stem
RIDE ALPHA Freeride 50
50 mm extension, 31,8 mm
Handlebar
RIDE ALPHA R20 E-Bike
31,8 mm, 780 mm width, 20 mm rise, Alloy 6061, electric wire internal routing
Grips
ODI Elite Motion
Soft pro compound, single clamp, black
Brakes
SHIMANO XT
4 pistons, I-Spec EV compatible
Shifters
SHIMANO XT
12s
Chain guide
RIDE ALPHA EP8
32-34t
Rear mech
SHIMANO XT
12s
Bottom bracket
SHIMANO
Crankset
E13 E*Spec Plus EP8
32t, Narrow-Wide, direct mount
Chain
SHIMANO XT
12s
Cassette
SHIMANO XT
12s, 10-51t
Rims
DT SWISS H1700 Spline
29'', 28h, 30 mm inner width
Hubs
Rear: DT SWISS 350 - Front: DT SWISS 350
Rear: 28h, sealed bearings, e-bike specific - Front: 28h, sealed bearings
Spokes/nipples
DT SWISS Hybrid
Straightpull, 2.34 / 1.8 / 2.0 mm, triple butted, stainless, with Nylok, black
Tyres
Rear: MAXXIS DHR II - Front: MAXXIS DHR II
Rear: 29 x 2.4, 3C, EXO+, Tubeless Ready - Front: 29 x 2.4, 3C, EXO+, Tubeless Ready
Seat post
Fox Transfer Factory
31,6 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L & XL, SHIMANO SL-MT500 remote
Saddle
WTB Silverado
Narrow shape, Cr-Mo rails
Weight
23,6 kg / 52,02 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
Yes
Colour
Keswick Green
Shiny Finish
Accessories
RIDE ALPHA CNC pedals, motor protector, chainstay protector, seatstay protector, user manual
META POWER bikes are delivered with Shimano Europlug (CEE 7/7 norm) battery charger, a plug adapter is necessary for customers living in countries using different standards.
Battery recycling
Partnership with SHIMANO
In partnership with SHIMANO, COMMENCAL supports a voluntary battery recycling program for ebike batteries. For each META POWER sold COMMENCAL will contribute 7EUR to fundraising organisation COREPILE. This sum is paid through SHIMANO France. When your battery reaches the end of its life, it would be great if you could send it back to us for recycling. Contact us for more info on the procedure.
