Price reduced from £7,300.00 to £5,700.00 -22%
id/sku : 22METAPWTRR
Availability: Select the model for availability null
Your size is not available? visit
  • Start
  • Specs
  • Tech
  • Size Chart
  • Video

The META POWER TR is quite simply our version of what Trail really means; up, down, jump, play and repeat, again and again. We've concentrated on three main areas - liveliness, responsiveness and agility. It's the perfect bike to get the most fun out of on the majority of trails around the world! With 150mm travel on the front and 140mm on the back, it's made for those who believe that having a playful bike whatever the terrain is the most important thing!

As an EMTB and Gravity brand, we know that it is essential to collaborate with recognised component specialists. Equipping the META POWER 29 with the SHIMANO EP8 engine was therefore an obvious choice. Why?
- It has a high torque (85N.m) whilst power curves are optimised.
- The result is a softer bike for better grip control and more responsiveness to each pedal stroke.
- The 630Wh battery increases capacity tenfold, perfect for long days.
- The position of the engine is designed to be lower than the battery to the maximum and optimise weight distribution.

This META POWER TR marks a real difference with the META POWER. With this in mind, the geometry has been specifically studied with regards to the intended use of the bike:
- The seat angle (77.5°) and the steerer angle (64.5°) are relatively straight.
- The position is ideal for pedalling and tackling the most technical climbs.

In addition, our expertise in the field of suspension in recent years has allowed us to articulate the kinematics of the META POWER TR around the Contact System -4bar linkage- which is designed to offer:
- Liveliness and efficiency when pedalling.
- Precise touchdown.
- Comfort.
- Reduced fatigue on big impacts.

In addition to all this in-depth work, like on our META POWER TR, META SX and CLASH bikes, we now offer a Flip Chip on the shock absorber extension in order to more acutely adjust the geometry, and therefore fit your personal style! This system means you can influence the height of the bottom bracket as well as the steerer and saddle angles within seconds. Depending on what you want, effectively, you can choose between a lively bike perfect for big pedalling missions, or more progressive bike ideal for days in bike park or on more committed lines.

The finishes on this POWER TR have also been worked on with care. Details make the difference:
- The motor mount has incorporated one of the advantages of the new EP8: its reduced size.
- The engine protection has high impact resistance and it's even better integrated into the general line of the bike thanks to a right side engine protection specific to META POWER.
- The charging connection is on the motor mount for easy access.
- The new more compact chain guide is also directly fixed to the engine mount.
- The routing on the chain stays has been reworked to avoid friction with frame paint.

POWER to our TRAILs!


Our META POWER TR RACE was immediately popular with this shiny Brushed finish.

And what about the complimentary ROCKSHOX red colours with it? The suspension combo is top-of-the-range, consistent with what we wanted from this bike.
- The famous ROCKSHOX Lyrik Ultimate has demonstrated quality in numerous Enduro World Series races in recent years. It is perfect for EMTB use.
- The Super Deluxe Ultimate Coil will delight the most demanding riders thanks to its sensitivity, flawless and unwavering behaviour whatever the terrain or weather.

Ultra-efficient, this META POWER TR RACE features excellent stopping power with the TRP DH-R Evo 4 pistons brakes, to ensure powerful and consistent braking in all circumstances. The SRAM GX Eagle 10-52t drivetrain has proved its reliability over many years. The DT SWISS HX1700 Spline EMTB-specific wheels complete this high-end build which is perfect for big trips in the mountains. Finally, the SHIMANO EP8 engine with 630WH battery powers this POWER.

This pot of top components make the META POWER TR RACE a formidable weapon on any type of trail.

*Please note that bike specs are subject to change without prior notice.

See more See less
  • Bicycle type

    E-BIKE TRAIL 29''

  • Frame material

    AL-6061 + AL-6066

  • Frame weight

    4,1 kg / 9.03 lb - With plastic accessories.

  • Rear travel

    140 mm

  • Shock length/stroke

    210 x 55 mm

  • Piggy back shock compatible


  • Shock bushings

    20 x 10 mm / NOTHING

  • Recommended/max. fork height

    566 mm / 576 mm

  • Headset dimension


  • Headset type

    ZS56 / ZS66

  • Maximum tyre dimension (etrto)

    65 mm - 622

  • Disc brake standard


  • Rear rotor max. size

    220 mm

  • Seatpost/seat clamp diameter

    31,6 mm / 34,9 mm

  • Bottom bracket type


  • ISCG

    Yes (SHIMANO Standard)

  • Rear hub compatibility

    12 x 148 mm

  • Frame

    2022 META POWER TR, 140 mm

    29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings

  • System


    Max. torque: 85N.m, 250W

  • Battery

    SHIMANO BT-E8036


  • Display


    LCD colored display featuring: Clock, Assist mode display, Battery charge level, Current Speed, Maximum speed, Average speed, Trip distance, Trip time, Estimated range, Range overview, Cadence, Human output power (as scale indicator), Calorie setting, Maintenance alert, Bluetooth LE connection (for E-Tube Project communication)

  • Shock

    ROCKSHOX Super Deluxe Coil Ultimate

    210 x 55 mm, LSC, rebound, 2-position adjustment. 210 x 55 mm, LSC, rebound, 2-position adjustment. Spring rate 350 LBS on S and M / 400 LBS on L / 450 LBS on XL

  • Fork

    ROCKSHOX Lyrik Ultimate, 150 mm travel

    29", Charger 2.1 damper, Debonair, LSC, HSC, rebound, Boost (15 x 110 mm), 42 mm offset, 2 Tokens

  • Headset

    ACROS ZS56 / ZS66

    Alloy cups, sealed bearings

  • Stem

    RIDE ALPHA Freeride 40

    40 mm extension, 31,8 mm

  • Handlebar


    Internal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

  • Grips

    ODI Elite Motion

    Soft pro compound, single clamp, black

  • Brakes

    TRP DH-R Evo

    4 pistons

  • Shifters

    SRAM GX Eagle

    12s, Single Click

  • Chain guide



  • Rear mech

    SRAM GX Eagle


  • Bottom bracket


  • Crankset

    E13 E*Spec Plus EP

    32t, Narrow-Wide, direct mount

  • Chain

    SRAM GX Eagle


  • Cassette

    SRAM GX Eagle

    12s, 10-52t

  • Rims

    Rear: DT SWISS HX1700 Spline - Front: DT SWISS HX1700 Spline

    Rear: 29'', 28h, welded, 30 mm inner width - Front: 29'', 28h, sleeved, 30 mm inner width

  • Hubs

    Rear: DT SWISS 350 - Front: DT SWISS 350

    Rear: 28h, sealed bearings, e-bike specific - Front: 28h, sealed bearings

  • Spokes/nipples

    DT SWISS Hybrid 1

    Straightpull, 2.34/2.0mm, double butted, stainless, with Nylok, black

  • Tyres

    Rear: SCHWALBE Nobby Nic - Front: SCHWALBE Magic Mary

    Rear: 29"x2.4", Super Trail, Addix SpeedGrip, Tubeless Easy - Front: 29"x2.4", Super Trail, Addix Soft, Tubeless Easy

  • Seat post

    KS Lev Integra

    31.6 mm, travel: 125 mm on S, 175 mm on M/L, 200 mm on XL, SouthPaw alloy remote

  • Saddle

    FIZIK Terra Aidon X3

    Kium Mobius rails

  • Weight

    24,8 kg / 54.67 lb

    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included


  • Colour


    Shiny Finish

  • Accessories

    RIDE ALPHA CNC pedals, motor protector, chainstay protector, seatstay protector, user manual

    META POWER bikes are delivered with Shimano Europlug (CEE 7/7 norm) battery charger, a plug adapter is necessary for customers living in countries using different standards.

  • Battery recycling

    Partnership with SHIMANO

    In partnership with SHIMANO, COMMENCAL supports a voluntary battery recycling program for ebike batteries. For each META POWER sold COMMENCAL will contribute 7EUR to fundraising organisation COREPILE. This sum is paid through SHIMANO France. When your battery reaches the end of its life, it would be great if you could send it back to us for recycling.
