COMMENCAL META TR V4 OHLINS EDITION ASH GREY

Price reduced from £5,100.00 to £4,000.00 -22%
id/sku : 22METATROHL
Availability: In stock null
Your size is not available? visit our european warehouse
  • Start
  • DESCRIPTION
  • TECHNICAL INFO
  • SPECIFICATIONS
  • SIZES
  • GEOMETRY
  • SPECS
  • TECHNICAL SPECIFICATIONS
  • Size Chart
  • Video
- DESCRIPTION -

ALL ABOUT META TR V4

The META TR V4 is our vision of trail riding. It is designed to make you really want to ride. Most at home when pedalling, it is even more at home when you let go of the brakes downhill, where it turns into a real mini-enduro. Well balanced, it excels during technical fast descents thanks to the aggressive kinematic/geometry combo. Rider positioning when climbing is ideal for long adventures. Flow trails, enduro, bike park, climbing, descents: nothing stands in its way.

META TR V4 - META SX V4: WHICH ONE TO CHOOSE?

META TR V4 ÖHLINS EDITION ASH GREY

The META TR ÖHLINS EDITION is designed for precise and committed riders. It benefits from all the knowledge and experience acquired by ÖHLINS in a race environment.

The RXF36 m.2 Air fork offers precision and excellent stability on slopes thanks to an air spring equipped with a specific Ramp Up chamber to adjust progressiveness at the end of the stroke, without forgetting its three-way setting TTX hydraulic cartridge.

The TTX1 Air shock ticks all the boxes. It offers excellent performance in terms of sensitivity, hold and hydraulics, with simple and precise adjustments.

SHIMANO take care of gear changes and braking with the Deore XT groupset. With 12-speed transmission, 4-piston calipers and 203mm discs, it has been a benchmark on the market for more than 40 years.

DT SWISS provide the rolling power with a pair of XM 1700 Spline wheels. With a welded rim for greater strength and durability, these aluminium wheels are intended to be versatile. The freehub of the DT 350 hubs inherits the 36-tooth crowns for instant engagement. Like all Swiss brand wheels, they are assembled by hand.

Finally, a SCHWALBE tyre combo of the Magic Mary and Nobby Nic Super Trail with Addix Soft and Grip rubber.

*Please note that bike specs are subject to change without prior notice.

See more See less
- TECHNICAL INFO -
  • Bicycle type

    Trail 29"

  • Frame material

    AL 6066 T4, T6

  • Frame weight

    3,7 kg / 8.15 lb

  • Rear travel

    140 mm

  • Shock length/stroke

    210 x 55 mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    Nothing on body - 20 x 10 mm on shaft

  • Recommended/max. fork height

    551 mm / 571 mm

  • Headset dimension

    Tapered

  • Headset type

    ZS44 / ZS56

  • Maximum tyre dimension (etrto)

    29" - 65 mm

  • Disc brake standard

    Postmount 200 mm

  • Rear rotor max. size

    220 mm

  • Seatpost/seat clamp diameter

    34,9 mm / 38,5 mm

  • Bottom bracket type

    BB92

  • ISCG

    ISCG 05

  • Rear hub compatibility

    L=180 mm, M12, P1.75 mm - Hub 12 x 148 mm standard maxle

- SPECIFICATIONS -
  • Frame

    META TR, 140 mm travel
    29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings

  • Shock

    OHLINS TTX1 Air
    210 x 55 mm, climb mode, Adjustable HSC (High-Speed Compression), LSC (Low-Speed Compression) and Rebound damping

  • Fork

    OHLINS RXF36 m.2 Air, 150 mm travel
    29", TTX 18 damper, Ramp Up chamber, LSC, HSC, rebound, climb mode, Boost (15 x 110 mm), 44 mm offset

  • Headset

    ACROS ZS44 / ZS56
    Alloy cups, sealed bearings

  • Stem

    RIDE ALPHA Freeride 40
    40 mm extension, 31,8 mm

  • Handlebar

    RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
    31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

  • Grips

    ODI Elite Motion
    Soft pro compound, single clamp, black

  • Brakes

    SHIMANO XT, 4 pistons, I-Spec EV compatible
    Rotors: Delivered with Shimano SM-RT86 or Galfer Disc Wave 203 mm, 6-bolt discs.

  • Shifters

    SHIMANO XT
    12s

  • REAR DERAILLEUR

    SHIMANO XT
    12s

  • Bottom bracket

    SHIMANO BBMT800
    Pressfit

  • Crankset

    SHIMANO XT, 170 mm crank arms, Boost
    Chainring: SHIMANO XT, 32t, Dynamic Chain Engagement + Technology

  • Chain

    SHIMANO XT
    12s

  • Cassette

    SHIMANO XT
    12s, 10-51t

  • Rims

    DT SWISS XM 1700
    29'', 28h, 30mm inner width

  • Hubs

    Rear: DT SWISS 350 - Front: DT SWISS 350
    Rear: 28h, sealed bearings, 12 x 148 mm, Micro Spline, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black

  • Spokes/nipples

    DT SWISS Competition
    Straightpull, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black

  • Tyres

    Rear: SCHWALBE Nobby Nic - Front: SCHWALBE Magic Mary
    Rear: 29" x 2.4", Super Trail, Addix Soft, Tubeless Easy - Front: 29" x 2.4", Super Trail, Addix Soft, Tubeless Easy

  • Seat post

    KS Lev Integra
    34.9 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L, 200 mm on XL, SouthPaw alloy remote

  • Saddle

    SDG Bel Air V3 Atmos
    140 mm width, Lux-Alloy Rails

  • Weight

    15 kg / 33.06 lb
    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included

    No

  • Colour

    Ash Grey
    Shiny Finish

  • Accessories

    Down tube protector, chainstay protector, seatstay protector

    *Please note that bike specs are subject to change without prior notice.
