ALL ABOUT META TR V4
The META TR V4 is our vision of trail riding. It is designed to make you really want to ride. Most at home when pedalling, it is even more at home when you let go of the brakes downhill, where it turns into a real mini-enduro. Well balanced, it excels during technical fast descents thanks to the aggressive kinematic/geometry combo. Rider positioning when climbing is ideal for long adventures. Flow trails, enduro, bike park, climbing, descents: nothing stands in its way.
META TR V4 - META SX V4: WHICH ONE TO CHOOSE?
META TR V4 RIDE
In this timeless Dirt colour with a matte finish, our META TR V4 RIDE blends into any environment.
with the RIDE model adventures are definitely on the cards, whether you've out for a couple of hours or several days:
- The ROCKSHOX Revelation RC fork has 35mm diameter stanchions which are stiff and precise, plus they're easy to adjust.
- The Deluxe Select + shock absorber allows you to quickly and easily adapt the behaviour of the bike depending on various factors.
- A SRAM SX Eagle 12-speed drivetrain will help you overcome the toughest obstacles.
- On the way downhill, the clean feel and reliability of the SRAM Guide T 4-piston brakes are guaranteed to stop you effectively.
- The KS Rage-I telescopic seat post provides real comfort and significant freedom of movement.
- The MAXXIS DHR II and Dissector tyres perfectly match this META TR 29 and give an excellent compromise between lateral grip and roll.
Everything you need.
*Please note that bike specs are subject to change without prior notice.
AL 6066 T4, T6
3,7 kg / 8.15 lb
210 x 55 mm
Piggy back shock compatible
Nothing on body - 20 x 10 mm on shaft
Recommended/max. fork height
551 mm / 571 mm
ZS44 / ZS56
Maximum tyre dimension (etrto)
29" - 65 mm
Disc brake standard
Postmount 200 mm
Rear rotor max. size
Seatpost/seat clamp diameter
34,9 mm / 38,5 mm
Bottom bracket type
Rear hub compatibility
L=180 mm, M12, P1.75 mm - Hub 12 x 148 mm standard maxle
Meta TR 29, 140 mm travel
29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
ROCKSHOX Deluxe Select +
210 x 55 mm, RT damper, DebonAir Linear, rebound, 2 pos comp, 1 Token neg. 4 Tokens pos.
ROCKSHOX Revelation RC, 150 mm travel
29", Motion Control RC damper, DebonAir, rebound, LSC, Boost (15 x 110 mm), 42 mm offset, 1 Token
ACROS ZS44 / ZS56
Alloy cups, sealed bearings
RIDE ALPHA Freeride 40
40 mm extension, 31,8 mm
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
ODI Elite Motion
Soft pro compound, single clamp, black
SRAM Guide T, 4 pistons, MatchMaker compatible
Rotors: SRAM G2 CleanSweep 200 mm, 6-bolt
SRAM SX Eagle
SRAM SX Eagle
SRAM X1 1000 Eagle, 170 mm crank arms, DUB, Boost
Chainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide
SRAM NX Eagle
E13 LG1 EN Base
29'', 32h, 30 mm inner width
Rear: FORMULA DCL-348A - Front: FORMULA DC-711
Rear: 32h, 12 x 148 mm, sealed bearings, Shimano Hyperglide - Front: 32h, 15 x 110 mm, sealed bearings
J-Bend, 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black
Rear: MAXXIS Dissector - Front: MAXXIS DHR II
Rear: 29" x 2.40", WT, EXO, dual compound, Tubeless Ready - Front: 29" x 2.40", WT, EXO, dual compound, Tubeless Ready
34.9 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote
SDG Bel Air V3
140 mm width, Steel Rails
15 KG / 33.06 LB
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Down tube protector, chainstay protector, seatstay protector
