New META TR 29: The best of both worlds!

When we developed the META TR 29, our intentions were clear - to make a bike that performs very well uphill but that also retains the COMMENCAL downhill DNA. We got the result we wanted thanks to a few key points:

- Large 29-inch wheels.

- Reworked and modifiable kinematics making the bike more dynamic.

- A straighter seat angle (and reduced offset).

The result is a particularly harmonious bike, a formidable pedaller and ideal companion for long active rides. The TR is seamlessly capable of transcending from uphill to downhill and soaking up all types of lumps and bumps in between. Thanks to 140mm of rear travel and the 150mm or 160mm fork, it tackles most obstacles without hesitation. Plus, the TR shows liveness and is playful when it comes to the terrain and pumping for speed etc. Mike Kazimer, reporter at Pinkbike, describes the META TR 29 as one of the funnest bikes he's ridden!

The stiffness of the frame is always the subject of much attention.

The use of double-row Enduro Bearings allows a more homogeneous deformation of the frame without the loss of stiffness via the bearings.

In addition to all this in-depth work, like on our META POWER TR, META SX and CLASH bikes, we now offer a Flip Chip on the shock absorber extension in order to more acutely adjust the geometry, and therefore fit your personal style! This system means you can influence the height of the bottom bracket as well as the steerer and saddle angles within seconds. Depending on what you want, effectively, you can choose between a lively bike perfect for big pedalling missions, or more progressive bike ideal for days in bike park or on more committed lines.


The META TR SIGNATURE has been designed to highlight the high-end components that adorn it. Could the matte Champagne paint inspire champagne showers?

Beyond just looks, this TR is a top-end build. Just take a look at:

- The FOX 36 Factory fork with Kashima treatment. It's a must thanks to its stiffness, unparalleled reactivity and the adjustment possibilities.

- The FOX Float X2 Factory shock is one of the best in terms of quality and performance thanks to its many adjustments and oversized air spring.

- You can't ask for much better than the SHIMANO XT groupset, a benchmark today for its reliability and consistency.

- The choice of wheels is important on a bike in this category, so we chose the DT SWISS XM1700 Spline for their excellent weight/liveliness/reliability ratio.

An exceptional bike, perfect for hilly and mountainous enduro stages.

See more See less
  • Bicycle type

    TRAIL 29"

  • Frame material


  • Frame weight

    3,7 kg / 8.15 lb

  • Rear travel

    140 mm

  • Shock length/stroke

    210 x 55 mm

  • Piggy back shock compatible


  • Shock bushings

    20 x 10 mm

  • Recommended/max. fork height

    551 mm / 571 mm

  • Headset dimension


  • Headset type

    ZS44 / ZS56

  • Maximum tyre dimension (etrto)

    65 mm

  • Disc brake standard

    POSTMOUNT 200 mm

  • Rear rotor max. size

    220 mm

  • Seatpost/seat clamp diameter

    34,9 mm / 38,5 mm

  • Bottom bracket type


  • ISCG

    ISCG 05

  • Rear hub compatibility

    12 x 148 mm

  • Frame

    2022 Meta TR, 140 mm travel

    29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings

  • Shock

    FOX Float X Factory

    210 x 55 mm, HSC, LSC, HSR,LSR, 2-postion adjustmentFOX 36 Factory, 160 mm travel

  • Fork

    FOX 36 Factory, 160 mm travel

    29", Grip 2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 44 mm offset, 1 Token

  • Headset

    ACROS ZS44 / ZS56

    Alloy cups, sealed bearings

  • Stem

    RIDE ALPHA Freeride 40

    40 mm extension, 31,8 mm

  • Handlebar

    RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL

    31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

  • Grips

    ODI Elite Motion

    Soft pro compound, single clamp, black

  • Brakes

    SHIMANO XT, 4 pistons, I-Spec EV compatible

    Rotor: Delivered with Shimano or Galfer discs.

  • Shifters



  • Chain guide


  • Rear mech



  • Bottom bracket



  • Crankset

    SHIMANO XT, 170 mm crank arms, Boost

    Chainring: SHIMANO XT, 32t, Dynamic Chain Engagement + Technology

  • Chain



  • Cassette


    12s, 10-51t

  • Rims

    DT SWISS XM 1700 29''

    29'', 28h, 30mm inner width

  • Hubs

    Rear: DT SWISS 350 - Front: DT SWISS 350

    Rear: 28h, sealed bearings, 12 x 148 mm, Micro Spline, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black

  • Spokes/nipples

    DT SWISS Competition

    Straightpull, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black

  • Tyres

    Rear: SCHWALBE Nobby Nic - Front: SCHWALBE Magic Mary

    Rear: 29" x 2.35", Super Trail, Addix Soft, Tubeless Ready - Front: 29" x 2.4", Super Trail, Addix Soft, Tubeless Easy

  • Seat post

    FOX Transfer Factory

    31.6 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L and 200 mm on XL, 1x lever + seat tube adaptor to 34.9 mm

  • Saddle

    FIZIK Terra Alpaca X5

    145 mm width, S-alloy rails

  • Weight

    15 kg / 33.06 lb

    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included


  • Colour


    Matte Finish

  • Accessories

    Down tube protector, chainstay protector, seatstay protector, Mudguard
