- DESCRIPTION -

CHECK OUT THE SUPREME DH V5

The SUPREME DH V5 is our ultimate race machine. Born from three years of collaboration between our R&D team and elite athletes, it delivered stunning results in its debut World Cup season: 9 wins, 27 podiums and top spots in the Elite Women’s, Men’s, and Team rankings.

Featuring our groundbreaking High Virtual Contact System kinematics, this bike redefines efficiency by merging responsiveness with unmatched shock absorption. Thanks to integrated aluminium frame inserts, its geometry and handling adapt to the day’s terrain, ensuring a ride tailored to your needs.

SUPREME DH V5 SETTINGS GUIDE

Frame not compatible with the new FOX Float X2 2026 shock.

See more See less
- TECHNICAL INFO -
  • Bicycle type

    Frame DH Racing

  • Frame material

    AL 6066 T4, T6

  • Frame weight

    5,4 kg / 11,9 lbs in size S with frame protections, chain guide, rear wheel axle

  • Rear travel

    220 mm

  • Shock length/stroke

    250 mm / 75 mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    30 x 8 mm / 30 x 8 mm

  • Recommended/max. fork height

    612 mm / 620 mm

  • Headset type

    ZS56 / ZS56

  • Maximum tyre dimension (etrto)

    65 mm

  • Disc brake standard

    Postmount 200 mm

  • Rear rotor max. size

    223 mm

  • Seatpost/seat clamp diameter

    31,6 mm / 34,9 mm

  • Bottom bracket type

    Press Fit BB 107

  • ISCG

    ISCG 05

  • Rear hub compatibility

    L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle

  • Accessories

    Down tube protector, chainstay protector, seatstay protector, rear wheel axle, chainguide, frame mudguard, roller cover, rear brake adaptor, rear hanger

  • Flip Chip
    Front / Up - Rear / Low (Available as an option: Front / Low - Rear / Up)
  • Hub Old
    157 x 12
  • Wheel Base Length
    Centered (Available as an option: Flip Flop +/-6mm)
  • Bridge
    XS & S: Thin - M & L: Medium - XL: Thick (All bridges are available as an option)
- SPECIFICATIONS -
  • Colour

    Glittery Burgundy - Shiny Finish

- SIZES -
- GEOMETRY -
SIZES
