COMMENCAL META TR V4 RACE BRUSHED

Price reduced from £4,500.00 to £3,600.00 -20%
id/sku : 22METATRRS
Availability: In stock null
Your size is not available? visit our european warehouse
  • Start
  • DESCRIPTION
  • TECHNICAL INFO
  • SPECIFICATIONS
  • SIZES
  • GEOMETRY
  • SPECS
  • TECHNICAL SPECIFICATIONS
  • Size Chart
  • Video
- DESCRIPTION -

ALL ABOUT META TR V4

The META TR V4 is our vision of trail riding. It is designed to make you really want to ride. Most at home when pedalling, it is even more at home when you let go of the brakes downhill, where it turns into a real mini-enduro. Well balanced, it excels during technical fast descents thanks to the aggressive kinematic/geometry combo. Rider positioning when climbing is ideal for long adventures. Flow trails, enduro, bike park, climbing, descents: nothing stands in its way.

META TR V4 - META SX V4: WHICH ONE TO CHOOSE?

META TR V4 RACE BRUSHED

This META TR RACE leaves no one indifferent. Minimalist and classy with its ‘Brushed’ aluminium frame and iconic red ROCKSHOX suspension, as its name suggests, it’s perfect for chasing the clock.

The ROCKSHOX Lyrik Ultimate fork is sure value. It features a stiff chassis for performance, a Charger 2.1 hydraulic cartridge with simple and precise adjustments, and a DebonAir pneumatic spring combining sensitivity and support.

The Super Deluxe Ultimate Coil shock combines impeccable sensitivity and excellent mid-stroke support thanks to its coil spring. Low speed compression is adjustable and can be locked out on the fly.

Braking is managed by TRP with a pair of DH-R Evos. They are the same as those used at World Cup races by Amaury Pierron. They are powerful, robust, progressive, and precise.

The SRAM GX Eagle 12-speed drivetrain features a wide 10-52t gear ratio. An example of reliability and precision which allows confident riding.

DT SWISS custom wheels are specifically designed for this bike. They consist of one of the best enduro rims on the market, the EX 511, combined with reliable and solid 350 hubs.

To offer maximum grip and performance we have chosen the MAXXIS Minion DHRII and Dissector tyres with EXO and EXO+ casing.

*Please note that bike specs are subject to change without prior notice.

See more See less
- TECHNICAL INFO -
  • Bicycle type

    Trail 29"

  • Frame material

    AL 6066 T4, T6

  • Frame weight

    3,7 kg / 8.15 lb

  • Rear travel

    140 mm

  • Shock length/stroke

    210 x 55 mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    Nothing on body - 20 x 10 mm on shaft

  • Recommended/max. fork height

    551 mm / 571 mm

  • Headset dimension

    Tapered

  • Headset type

    ZS44 / ZS56

  • Maximum tyre dimension (etrto)

    29" - 65 mm

  • Disc brake standard

    Postmount 200 mm

  • Rear rotor max. size

    220 mm

  • Seatpost/seat clamp diameter

    34,9 mm / 38,5 mm

  • Bottom bracket type

    BB92

  • ISCG

    ISCG 05

  • Rear hub compatibility

    L=180 mm, M12, P1.75 mm - Hub 12 x 148 mm standard maxle

- SPECIFICATIONS -
  • Frame

    META TR, 140 mm travel
    29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings

  • Shock

    ROCKSHOX Super Deluxe Coil Ultimate
    210 x 55 mm, RCT damper,  LSC, rebound, 2-position (open/firm). Spring rates: 350lbs on S/M, 400lbs on L, 450lbs on XL

  • Fork

    ROCKSHOX Lyrik Ultimate, 160 mm travel
    29", Charger 2.1 damper, DebonAir, LSC, HSC, rebound, Boost (15 x 110 mm), 42 mm offset, 2 Tokens

  • Headset

    ACROS ZS44 / ZS56
    Alloy cups, sealed bearings

  • Stem

    RIDE ALPHA Freeride 40
    40 mm extension, 31,8 mm

  • Handlebar

    RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
    31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

  • Grips

    ODI Elite Motion
    Soft pro compound, single clamp, black

  • Brakes

    TRP DH-R Evo, 4 pistons
    Rotors: TRP R1 203 mm, 6-bolt, 2.3 mm width

  • Shifters

    SRAM GX Eagle
    12s

  • Chain guide

    -

  • REAR DERAILLEUR

    SRAM GX Eagle
    12s

  • Bottom bracket

    SRAM DUB
    Pressfit

  • Crankset

    SRAM GX Eagle, 170 mm crank arms, DUB, Boost
    Chainring: SRAM GX Eagle, 32t, Narrow-Wide

  • Chain

    SRAM GX Eagle
    12s

  • Cassette

    SRAM XG-1275 Eagle
    12s, 10-52t

  • Rims

    DT SWISS EX511
    29'', 28h, 30 mm inner width

  • Hubs

    Rear: DT SWISS 350 - Front: DT SWISS 350Rear: 28h, sealed bearings, 12 x 148 mm, XD driver, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black

  • Spokes/nipples

    DT SWISS Competition
    Straightpull, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black

  • Tyres

    Rear: MAXXIS Dissector - Front: MAXXIS DHR II
    Rear: 29" x 2.40", WT, EXO+, 3C MaxxTerra, Tubeless Ready - Front: 29" x 2.40", WT, EXO, 3C MaxxGrip, Tubeless Ready

  • Seat post

    KS Lev Integra
    34.9 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L, 200 mm on XL, SouthPaw alloy remote

  • Saddle

    SDG Bel Air V3 Atmos
    140 mm width, Lux-Alloy Rails

  • Weight

    15,9 kg / 35.05 lb
    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included

    No

  • Colour

    Brushed
    Shiny Finish

  • Accessories

    Down tube protector, chainstay protector, seatstay protector

    *Please note that bike specs are subject to change without prior notice.

- SIZES -
- GEOMETRY -
SIZES
