COMMENCAL SUPREME DH V5 SIGNATURE GLITTERY BLACK ALC - M (22102058)

Price reduced from $7,800.00 to $6,950.00 -11%
id/sku : OCUSA917
Availability: This Item is currently not available. null
BUY IN-STORE
You can place your order and have the COMMENCAL product of your choice delivered directly to your nearest store. Your store will need to contact our B2B SALES DEPARTMENT to register your order. Your store receives the product and you will pay directly with them. The store will inform you of the receipt of your order.
- DESCRIPTION -

Our refurbished bikes come from our demo fleets, test fleets and returns for shipping damage.
We perform a thorough check of each bike and replace all wearing and damaged parts.
While they may have cosmetic imperfections, our refurbished bikes are ready to ride.
These bikes are final sale but come with a full warranty.

- GENERAL DESCRIPTION -

Bike is in new working condition.

- COSMETIC DESCRIPTION -

Like New.

- MECHANICAL DESCRIPTION -

None.


Don’t hesitate to contact us for more details.

See more See less
- Video -
- TECHNICAL INFO -
  • Bicycle type

    Frame DH Racing

  • Frame material

    AL 6066 T4, T6

  • Frame weight

    5,3 kg / 11,68 lbs in size S with frame protections, chain guide, rear wheel axle

  • Rear travel

    220 mm

  • Shock length/stroke

    250 mm / 75 mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    30 x 8 mm / 30 x 8 mm

  • Recommended/max. fork height

    612 mm / 620 mm

  • Headset type

    ZS56 / ZS56

  • Maximum tyre dimension (etrto)

    65 mm

  • Disc brake standard

    Postmount 200 mm

  • Rear rotor max. size

    223 mm

  • Seatpost/seat clamp diameter

    31,6 mm / 34,9 mm

  • Bottom bracket type

    Press Fit BB 107

  • ISCG

    ISCG 05

  • Rear hub compatibility

    L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle

  • Flip Chip
    Front / Up
  • Wheel Base Length
    Centered
  • Bridge
    XS & S : Thin - M & L : Medium - XL : Thick
- SPECIFICATIONS -
  • Frame

    SUPREME DH V5 29/27, 220 mm travel
    27/29'', Alloy 6066, triple butted tubes, T4, T6.

  • Shock

    FOX Float X2 Factory
    250 x 75 mm, HSC, LSC, HSR, LSR, 0.3 Spacer x3

  • Fork

    FOX 40 Factory, 203 mm travel
    29", Grip X2 damper, HSC, LSC, HSR, LSR, Float Evol. Boost (20 x 110 mm), 52 mm offset, 2 spacers.

  • Headset

    CANECREEK ZS56/ZS56 SERIE 40
    Alloy cups, sealed bearings

  • Stem

    RENTHAL
    integra 45mm

  • Handlebar

    RENTHAL FATBAR
    30mm rise

  • Grips

    RIDE ALPHA

  • Brakes

    TRP DH-R EVO, 4 pistons, resin pads
    Rotors: TRP R1 220 mm, 6-bolt, 2.3 mm width

  • Shifters

    SRAM GX DH
    7s

  • Chain guide

    E13 LG1
    32-34t

  • REAR DERAILLEUR

    SRAM GX Eagle
    7s

  • Bottom bracket

    SRAM DUB
    Pressfit

  • Crankset

    SRAM Descendant DH, 165 mm crank arms, DUB
    Chainring: SRAM Descendant DH, 34t

  • Chain

    SRAM PC 1130
    11s

  • Cassette

    SRAM PG-720 DH
    7s, 11-25t

  • Rims

    DT SWISS FR 560
    Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width

  • Hubs

    DT SWISS DT 350
    Rear: 32h, sealed bearings, 12 x 157 mm, 36t, Sram XD - Front: 32h, sealed bearings, 20 x 110 mm Boost

  • Spokes/nipples

    DT SWISS Competition
    J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with ProLock, black

  • Tyres

    Rear: SCHWALBE Magic Mary - Front: SCHWALBE Magic Mary

  • Seat post

    RIDE ALPHA
    31.6 mm, 250 mm

  • Saddle

    WTB SILVERADO
    Medim steel

  • Weight

    - kg / - lbs
    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included

    No

  • Colour

    Glittery Black
    Shiny Finish

  • Accessories

    Chainstay protector, seatstay protector, fork bumpers, downtube protector, Fox 40 fender
    *Please note that bike specs are subject to change without prior notice
