COMMENCAL META POWER TR BOSCH OHLINS EDITION EMERALD GREEN - L (22180403) 412m

Frame

META POWER TR BOSCH, 140 mm
29", Alloy 6066, triple butted tubes, T4, T6.

Motor

BOSCH Performance Line CX
Max. torque: 85N.m, 250W

Battery

BOSCH PowerTube 625, 625Wh
BOSCH 4A Charger, Compact size & lightweight

Compatible w/Bosch PowerMore 250 for extra range

Display

BOSCH System Controller
BOSCH Mini Remote currently not available in the USA

Shock

OHLINS TTX22 Air
210 x 55 mm, climb mode, LSC, 3 positions HSC, rebound

Fork

OHLINS RXF36 m.2 Air, 150 mm travel
29", TTX 18 damper, climb mode, LSC, 3 positions HSC, rebound, Boost (15 x 110 mm), 44 mm offset

Headset

ACROS ZS56 / ZS66
Alloy cups, sealed bearings

Stem

RIDE ALPHA 40 EXTERNAL
40 mm extension, 31,8 mm

Handlebar

DEITY

Grips

ODI LONGNECK
Soft compound, single clamp, black

Brakes

SHIMANO XT, 4 pistons, resin pads, I-Spec EV compatible
Rotors: SHIMANO SM-RT66 220 mm, 6-bolt

Shifters

SHIMANO Deore XT
12s

Chain guide

RIDE ALPHA Upper Guide
32-34t

REAR DERAILLEUR

SHIMANO Deore XT
12s

Bottom bracket

BOSCH

Crankset

E13 E*Spec Plus Bosch CX, 160 mm crank arms
Chainring: E13 E*Spec Plus Bosch CX, 34t, direct mount

Chain

SHIMANO SLX
12s

Cassette

SHIMANO Deore XT
12s, 10-51t

Rims

Rear: DT SWISS HX1700 Spline - Front: DT SWISS HX1700 Spline
Rear: 29'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width

Hubs

Rear: DT SWISS 350 - Front: DT SWISS 350
Rear: 28h, 12 x 148 mm, sealed bearings, 24t, e-bike specific, Sram XD - Front: 28h, 15 x 110 mm, sealed bearings

Spokes/nipples

DT SWISS Hybrid 1
Straightpull, 2.34/2.0mm, double butted, stainless, with ProLock, black

Tyres

Rear: MAXXIS DHR II - Front: MAXXIS DHR II
Rear: 29"x2.4" - Front: 29"x2.4"

Seat post

KS Lev Integra
31.6 mm, travel: 125 mm on S, 175 mm on M/L, 200 mm on XL, SouthPaw alloy remote

Saddle

FIZIK Terra Aidon X3
145 mm width, Kium Mobius rails

Weight

23.8 kg / 52.47 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

Pedals included

Yes

Colour

Emerald Green
Shiny Finish

Accessories

RIDE ALPHA CNC pedals, motor protector, chainstay protector, seatstay protector, user manual
*Actual product may differ from pictures.
*Please note that bike specs are subject to change without prior notice.

Battery recycling

Partnership with BOSCH
The battery (used up, damaged, defective) must be recycled. Each national distributor is responsible for providing the dealer with a free recycling solution.

Applicable laws: Battery Act, Directive 2006/66/EC, BattG in Germany too.

Robert Bosch GmbH recommends concluding a contract with a national service provider for returning batteries in each case.
