COMMENCAL META SX V5 RIDE PYRITE GREY

Price reduced from $3,800.00 to $3,200.00 -16%
id/sku : 23METASXRI
Availability: Select the model for availability null
  • Start
  • DESCRIPTION
  • TECHNICAL INFO
  • SPECIFICATIONS
  • SIZES
  • GEOMETRY
  • SPECS
  • TECHNICAL SPECIFICATIONS
  • Size Chart
  • Video
- DESCRIPTION -

ALL ABOUT META SX V5

The META SX V5 is driven before its ridden. The 165mm of travel is combined with our new Virtual Contact System (VCS) kinematics. Even more effective, it comes into its own when released in the bike park or on steep trails. This is a bike for riders looking for an enduro bike that feels as close to a DH bike as possible.

META V5 - META SX V5: WHICH ONE TO CHOOSE?

META SX V5 RIDE PYRITE GREY

The META SX V5 RIDE benefits from a duo of ROCKSHOX suspension. On the front, we feature the 170mm Zeb with a terrain-proof chassis and 38mm stanchions. It inherits the new DebonAir+ spring and the new Rush RC hydraulic cartridge. On the back, the Super Deluxe Select+. By tweaking the negative and positive air volumes, you can adapt it specifically to your tastes. The end-of-stroke travel is also better managed, and the additional cartridge increases the volume of oil for more consistency.

It's SRAM for braking with a pair of DB8s. These new brakes are designed for intensive braking and limited maintenance thanks to the use of mineral oil.

We equipped this META SX V5 RIDE with a SRAM NX EAGLE 12-speed drivetrain. The ultra-wide range helps make it possible to face all the steep and uneven terrain.

Finally, SPANK Spike Race 33 rims because their solidity is already proven. We added MAXXIS Assegai EXO and Minion DHRII EXO+ tyres for the perfect combo.

*Please note that bike specs are subject to change without prior notice.

See more See less
- Video -
- TECHNICAL INFO -
  • Bicycle type

    ENDURO 27/29"

  • Frame material

    Al 6061 T6, Al 6066 T6

  • Frame weight

    3,3 kg / 7.27 lb, raw without accessories

  • Rear travel

    165 mm

  • Shock length/stroke

    230 x 65 mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    NOTHING ON BODY / 20 X 10 mm ON SHAFT

  • Recommended/max. fork height

    586 mm / 44 mm

  • Headset type

    ZS56 / ZS56, Integrated cable routing

  • Maximum tyre dimension (etrto)

    64 mm / diam. 721

  • Disc brake standard

    Postmount 200 mm

  • Rear rotor max. size

    223 mm

  • Seatpost/seat clamp diameter

    34,9 mm / 38,6 mm

  • Bottom bracket type

    Press Fit BB 92

  • ISCG

    ISCG 05

  • Rear hub compatibility

    L=180 mm, M12, P1.0 mm - Hub 12 x 148 mm standard maxle

- SPECIFICATIONS -
  • Frame

    META SX V5, 165 mm travel
    29''-27.5'', Alloy 6066, triple butted tubes, T4, T6

  • Shock

    ROCKSHOX Super Deluxe Select +
    230 x 65 mm, RT damper, DebonAir, rebound, 2 position compression adjustment, 0 Token neg. 3 Tokens pos.

  • Fork

    ROCKSHOX Zeb Base, 170 mm travel
    29", Rush RC damper, DebonAir+, LSC, rebound, Boost (15 x 110 mm), 44 mm offset, 1 Token

  • Headset

    ACROS ZS56 / ZS56
    Alloy cups, sealed bearings

  • Stem

    RIDE ALPHA 40
    40 mm extension, 31,8 mm

  • Handlebar

    RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
    31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

  • Grips

    ODI Longneck
    Soft compound, single clamp, black

  • Brakes

    SRAM DB8, 4 pistons, steel-backed organic pads, MatchMaker compatible
    Rotors: SRAM G2 CleanSweep 200 mm, 6-bolt

  • Shifters

    SRAM NX Eagle
    12s

  • Chain guide

    RIDE ALPHA
    32t-34t

  • REAR DERAILLEUR

    SRAM NX Eagle
    12s

  • Bottom bracket

    SRAM DUB WIDE
    Pressfit

  • Crankset

    SRAM X1 1000 Eagle, 165 mm crank arms, DUB, Boost
    Chainring: SRAM Eagle, 32t, Narrow-Wide

  • Chain

    SRAM NX Eagle
    12s

  • Cassette

    SRAM PG-1210
    12s, 11-50t

  • Rims

    SPANK SPIKE RACE 33
    Rear: 27.5'', 32h, 28 mm inner width - Front: 29'', 32h, 28 mm inner width

  • Hubs

    Rear: FORMULA DCL-348A - Front: FORMULA DC-711
    Rear: 32h, sealed bearings, 12 x 148 mm, Shimano Hyperglide - Front: 32h, sealed bearings, 15 x 110 mm

  • Spokes/nipples

    SAPIM Race
    J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black

  • Tyres

    Rear: MAXXIS DHR II - Front: MAXXIS Assegai
    Rear: 27.5"x2.4" WT, 3C MaxxTerra, EXO+, Tubeless Ready - Front: 29"x2.5" WT, 3C MaxxTerra, EXO, Tubeless Ready

  • Seat post

    KS Rage-i
    34.9 mm, travel: 125 mm on S, 170 mm on M/L and 190 mm on XL, SouthPaw alloy remote

  • Saddle

    SDG Bel Air V3
    140 mm width, steel rails

  • Weight

    16,1 kg / 35.49 lb
    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included

    No

  • Colour

    Pyrite Grey
    Shiny Finish

  • Accessories

    Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender
    *Please note that bike specs are subject to change without prior notice.
