COMMENCAL SUPREME DH V5 ESSENTIAL HERITAGE GREEN

Price reduced from $6,600.00 to $5,700.00 -14%
id/sku : 22SUPV5R
Availability: Select the model for availability null
BUY IN-STORE
You can place your order and have the COMMENCAL product of your choice delivered directly to your nearest store. Your store will need to contact our B2B SALES DEPARTMENT to register your order. Your store receives the product and you will pay directly with them. The store will inform you of the receipt of your order.
c
- DESCRIPTION -

CHECK OUT THE SUPREME DH V5

SUPREME DH V5: Engineered for Performance, Built to Win
The SUPREME DH V5 is the ultimate race machine, born from three years of dedicated collaboration between our R&D team and elite athletes. From its very first season competing in World Cup events, the SUPREME DH V5 has proven its dominance: 9 victories, 27 podium finishes, and first-place rankings in the Elite Women, Men, and Team categories. This success speaks for itself.

Precision Engineering: High Virtual Contact System (HVCS) Kinematics
At the heart of the SUPREME DH V5 is our groundbreaking High Virtual Contact System (HVCS), a suspension kinematic designed to optimize both responsiveness and shock absorption. The result? Exceptional control and adaptability on even the toughest terrain.

With adjustable geometry inserts integrated into the aluminum frame, riders can fine-tune the bike’s behavior to match specific course conditions, ensuring optimal performance for every race.

SUPREME DH V5 SETTINGS GUIDE


COMMENCAL SUPREME DH V5 ESSENTIAL HERITAGE GREEN: Built for the Essentials

The SUPREME DH V5 ESSENTIAL lives up to its name—focusing on the core elements of downhill performance without compromise. Every component is chosen for precision, durability, and rider-focused functionality, delivering a smooth and controlled descent.

High-Performance Components for Ultimate Control:
- FOX 40 Performance Fork:
Featuring an adjustable air spring and a GRIP hydraulic cartridge, this fork allows on-the-fly low-speed compression adjustment—perfect for fast-paced trail changes.
- FOX DHX2 Performance Elite Shock: With 4-way adjustability and unmatched sensitivity, this shock maintains performance without overheating, no matter the length or intensity of the descent.
- TRP DH-R Evo Brakes: These 4-piston brakes with 223mm rotors deliver powerful, reliable, and precise braking. Designed for progressive control, they excel on steep, technical trails.
- E13 LG1+ DH Wheels: Known for their strength and durability, these wheels feature a wide spoke umbrella for enhanced lateral stiffness, thanks to the integrated freehub body and cassette design.
- SRAM GX DH Drivetrain: Engineered for downhill, the SRAM GX DH derailleur ensures smooth and responsive shifting under pressure, keeping you in control at high speeds.

Maximum Grip with MAXXIS Tire Combo
The MAXXIS Assegai and Minion DHR II tires (DH casing) offer the ideal balance of traction and stability. Whether navigating wet roots or hard-packed dirt, these tires deliver confidence-inspiring grip that pushes your limits without losing control.

Conclusion: Race-Ready, Trail-Proven
The SUPREME DH V5 ESSENTIAL is not just a bike—it’s a statement of downhill excellence. Combining advanced engineering with proven race components, it’s designed for those who demand the very best from their equipment. Get ready to ride at the edge of performance and set your sights on the podium.

*Please note that bike specs are subject to change without prior notice.

See more See less
- Video -
- TECHNICAL INFO -
  • Bicycle type

    Cadre DH 29''/27''

  • Frame material

    AL 6066 T4, T6

  • Frame weight

    5,4 kg / 11,9 lbs in size S with frame protections, chain guide, rear wheel axle

  • Rear travel

    220 mm

  • Shock length/stroke

    250 x 75

  • Piggy back shock compatible

    Yes

  • Shock bushings

    20 x 10 mm / 30 x 8 mm

  • Recommended/max. fork height

    630 mm / 638 mm

  • Headset type

    ZS56 / ZS56

  • Maximum tyre dimension (etrto)

    64 mm / diam 721

  • Disc brake standard

    Postmount 200 mm

  • Rear rotor max. size

    223 mm

  • Seatpost/seat clamp diameter

    31,6 mm / 34,9 mm

  • Bottom bracket type

    Press Fit BB 107

  • ISCG

    ISCG 05

  • Rear hub compatibility

    L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle

  • Flip Chip
    Front / Up - Rear / Low (Available as an option: Front / Low - Rear / Up)
  • Wheel Base Length
    Centered (Available as an option: Flip Flop +/-6mm)
  • Bridge
    XS & S: Thin - M & L: Medium - XL: Thick (All bridges are available as an option)
- SPECIFICATIONS -
  • Frame

    SUPREME DH V5 29/27, 220 mm travel on S / M / L / XL
    27/29'', Alloy 6066, triple butted tubes, T4, T6

  • Shock

    FOX DHX 2 Performance Elite
    250 x 75 mm, LSC, LSR. Spring rates: 400 lbs on S, 450 lbs on M, 500 lbs on L, 500 lbs on XL

  • Fork

    FOX 40 Performance, 203 mm travel
    29", Grip damper, LSC, Float Evol. Boost (20 x 110 mm), 52 mm offset, 2 spacers

  • Headset

    ACROS ZS56 / ZS56
    Alloy cups, sealed bearings

  • Stem

    RIDE ALPHA DH 40
    40 mm extension, direct mount, 31.8 mm

  • Handlebar

    RIDE ALPHA R27
    31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on  XL

  • Grips

    ODI Elite Motion
    Soft pro compound, single clamp, black

  • Brakes

    TRP DH-R Evo, 4 pistons, resin pads
    Rotors : TRP R1 223 mm, 6-bolt, 2.3 mm thickness

  • Shifters

    SRAM GX DH
    7 sp

  • Chain guide

    E13 LG1 + Bottom Guide
    32-34t

  • REAR DERAILLEUR

    SRAM GX DH
    7 sp

  • Bottom bracket

    SRAM DUB
    Pressfit

  • Crankset

    TRUVATIV Descendant DH, 165 mm crank arms, DUB
    Chainring: TRUVATIV Descendant DH X-Sync, 34t

  • Chain

    KMC X11EL
    Black

  • Cassette

    E13 LG1 Plus DH
    7s, 9-21t DM Cassette

  • Rims

    E13 LG1 Plus DH
    Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width

  • Hubs

    Rear: E13 LG1 Plus DH - Front: E13 LG1 Plus DH
    Rear: 32h, sealed bearings, 12 x 157 mm, black - Front: 32h, sealed bearings, 20 x 110 mm Boost, black

  • Tyres

    Rear: MAXXIS DHR II - Front: MAXXIS Assegai
    Rear: 27.5'' x 2.4'', WT, 3C MaxxGrip, DH Casing, Tubeless Ready - Front: 29" x 2.5", WT, 3C MaxxGrip, Double Down, Tubeless Ready

  • Seat post

    RIDE ALPHA Super Light
    31.6 mm, 250 mm length

  • Saddle

    FIZIK Gravita Alpaca X5
    130 mm width, S-Alloy rails

  • Weight

    17,5 kg / 38,58 lbs
    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included

    No

  • Colour

    Heritage Green
    Shiny Finish

  • Accessories

    Chainstay protector, seatstay protector, downtube protector, roller cover, frame mudguard, fork fender specific Fox 40
    *Please note that bike specs are subject to change without prior notice.
