COMMENCAL META TR V4 ESSENTIAL DARK SLATE

Price reduced from £4,100.00 to £3,000.00 -27%
id/sku : 22METATREGRL
Availability: In stock null
Your size is not available? visit our european warehouse
  • Start
  • DESCRIPTION
  • TECHNICAL INFO
  • SPECIFICATIONS
  • SIZES
  • GEOMETRY
  • SPECS
  • TECHNICAL SPECIFICATIONS
  • Size Chart
  • Video
- DESCRIPTION -

ALL ABOUT META TR V4

The META TR V4 is our vision of trail riding. It is designed to make you really want to ride. Most at home when pedalling, it is even more at home when you let go of the brakes downhill, where it turns into a real mini-enduro. Well balanced, it excels during technical fast descents thanks to the aggressive kinematic/geometry combo. Rider positioning when climbing is ideal for long adventures. Flow trails, enduro, bike park, climbing, descents: nothing stands in its way.

META TR V4 - META SX V4: WHICH ONE TO CHOOSE?

META TR V4 ESSENTIAL DARK SLATE

The META TR ESSENTIAL plays the classy card with a matte finish and matching black components.

The FOX 36 Performance fork has a rigid chassis for maximum precision. It features the three-position GRIP cartridge and the Float Evol air spring which allows the rider to precisely adjust the stiffness according to their tastes and size.

The FOX Float DPS shock absorber is suited to all riders thanks to the air spring. It also offers a three-position compression adjustment.

SHIMANO take care of managing gear changes and braking with the SLX groupset. The 12-speed drivetrain is particularly reliable with a wide gear ratio (10-51) that is perfect for adventures with a lot of climbing.

The 4-piston brakes with 203mm discs offer a clean and powerful feel for calm and consistent braking in all conditions.

DT SWISS provide the wheels on this ESSENTIAL model. We find the high-end all-mountain aluminium rims: the M 502. These wheels are distinguished by their excellent weight/strength ratio.

The MAXXIS Minion DHR II and Dissector tyres with EXO casing offer an excellent combination of lateral grip and performance.

*Please note that bike specs are subject to change without prior notice.

See more See less
- Video -
- TECHNICAL INFO -
  • Bicycle type

    Trail 29"

  • Frame material

    AL 6066 T4, T6

  • Frame weight

    3,7 kg / 8.15 lb

  • Rear travel

    140 mm

  • Shock length/stroke

    210 x 55 mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    Nothing on body - 20 x 10 mm on shaft

  • Recommended/max. fork height

    551 mm / 571 mm

  • Headset dimension

    Tapered

  • Headset type

    ZS44 / ZS56

  • Maximum tyre dimension (etrto)

    29" - 65 mm

  • Disc brake standard

    Postmount 200 mm

  • Rear rotor max. size

    220 mm

  • Seatpost/seat clamp diameter

    34,9 mm / 38,5 mm

  • Bottom bracket type

    BB92

  • ISCG

    ISCG 05

  • Rear hub compatibility

    L=180 mm, M12, P1.75 mm - Hub 12 x 148 mm standard maxle

- SPECIFICATIONS -
  • Frame

    META TR, 140 mm travel
    29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings

  • Shock

    FOX Float DPS Performance
    210 x 55 mm, rebound, 3 position adjustment

  • Fork

    FOX 36 Performance, 150 mm travel
    29", Fit Grip damper, 3 positions, rebound, Boost (15 x 110 mm), 44 mm offset, 2 Tokens

  • Headset

    ACROS ZS44 / ZS56
    Alloy cups, sealed bearings

  • Stem

    RIDE ALPHA Freeride 40
    40 mm extension, 31,8 mm

  • Handlebar

    RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
    31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

  • Grips

    ODI Elite Motion
    Soft pro compound, single clamp, black

  • Brakes

    SHIMANO SLX, 4 pistons, I-Spec EV compatible
    Rotors: SHIMANO SM-RT76 203 mm, 6 holes

  • Shifters

    SHIMANO SLX
    12s

  • Chain guide

    -

  • REAR DERAILLEUR

    SHIMANO SLX
    12s

  • Bottom bracket

    SHIMANO BB71-41A
    Pressfit

  • Crankset

    SHIMANO SLX, 170 mm crank arms, Boost
    Chainring: SHIMANO SLX, 32t, Dynamic Chain Engagement + Technology

  • Chain

    SHIMANO SLX
    12s

  • Cassette

    SHIMANO SLX
    12s, 10-51t

  • Rims

    DT SWISS M 502
    29'', 32h, 30 mm inner width

  • Hubs

    Rear: FORMULA MSL-148A - Front: FORMULA DC-711
    Rear: 32h, 12 x 148 mm, sealed bearings, Micro Spline - Front: 32h, 15 x 110 mm, sealed bearings

  • Spokes/nipples

    SAPIM Race
    J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black

  • Tyres

    Rear: MAXXIS Dissector - Front: MAXXIS DHR II
    Rear: 29" x 2.40", WT, EXO, dual compound, Tubeless Ready - Front: 29" x 2.40", WT, EXO, dual compound, Tubeless Ready

  • Seat post

    KS Rage-I
    34.9 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote

  • Saddle

    FIZIK Terra Alpaca X5
    145 mm width, S-alloy rails

  • Weight

    15 kg / 33.06 lb
    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included

    No

  • Colour

    Dark Slate
    Matte Finish

  • Accessories

    Down tube protector, chainstay protector, seatstay protector

    *Please note that bike specs are subject to change without prior notice.
