COMMENCAL META SX V4 ALC HIGH POLISHED image number null

Contractual photo - Components and accessories may exceptionally differ from those specified in the specifications.

COMMENCAL META SX V4 ALC HIGH POLISHED

This UNIQUE model is produced in a single version with an exclusive colour, and benefits from hand assembly in our workshop.

LEARN MORE ABOUT THIS BIKE
Price reduced from A$ 7,727.27 excl. GST to A$ 6,272.72 excl. GST -19%
id/sku : 22METAAMALCHP3
  SIZE GUIDE
Availability: Select the size to see null
BUY IN-STORE

You can place your order and have the COMMENCAL product of your choice delivered directly to your nearest store. Your store will need to contact our B2B SALES DEPARTMENT to register your order. Your store receives the product and you will pay directly with them. The store will inform you of the receipt of your order.

COMMENCAL META SX V4 ALC HIGH POLISHED image cover number large 0
COMMENCAL META SX V4 ALC HIGH POLISHED image cover number large 1
COMMENCAL META SX V4 ALC HIGH POLISHED image cover number large 2

Unmissable in its polished finish, this META SX V4 is kitted with a lineup of premium components. The full FOX Factory Kashima suspension setup with the 38 fork up front and Float X2 shock on the back delivers unmatched trail sensitivity. Braking is handled with the 4-piston SRAM Code RSC, while shifting duties go to the SRAM GX Eagle 12-speed drivetrain. DT SWISS wheels, featuring EX 511 rims and 350 hubs, guarantee strength and precision. MAXXIS Assegai / Minion DHR II tyres with EXO+ casing round out a setup that’s both reliable and performance driven. Robust, precise, and eager to shred, this model delivers pure riding sensations.

specifications

  • Frame

    META SX V4, 160 mm travel
    29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearing

  • Shock

    FOX Float X2 Factory
    230x62,5mm, HSC, LSC, HSR,LSR, 2-postion adjustment

  • Fork

    FOX 38 Factory, 170mm travel
    29", Grip 2 damper, HSC, LSC, HSR, LSR, Boost (15x110mm), 44mm offset, 1 Token

  • Headset

    CANE CREEK Hellbender 70 ZS44 / ZS56
    Alloy cups, sealed bearings

  • Stem

    RENTHAL Apex
    40mm extension, 31,8 mm aluminium

  • Handlebar

    RENTHAL Fatbar V2
    31,8mm, 800mm width, 20mm rise, aluminium, Alugold

  • Grips

    ODI AG2
    Lock on, Black

  • Brakes

    SRAM Code RSC
    4 pistons

  • Shifters

    SRAM GX Eagle
    12s

  • Chain guide

    RIDE ALPHA Enduro
    ISCG 05, chain guide + bash guard

  • REAR DERAILLEUR

    SRAM GX Eagle
    12s

  • Bottom bracket

    SRAM DUB
    Pressfit BB92 DUB

  • Crankset

    SRAM GX Eagle, 170 mm crank arms, DUB, Boost
    Chainring: SRAM GX Eagle, 32t, Narrow-Wide

  • Chain

    SRAM SX Eagle
    12s

  • Cassette

    SRAM GX Eagle
    12s, 10-52t

  • Rims

    Rear: DT SWISS EX511 27.5'' - Front: DT SWISS EX511 29''
    Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width

  • Hubs

    Rear: DT SWISS 350 - Front: DT SWISS 350
    Rear: 28h, sealed bearings, 12 x 148 mm, XD driver, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black

  • Spokes/nipples

    DT SWISS Competition
    Straightpull, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black

  • Tyres

    Rear: MAXXIS Assegai - Front: MAXXIS Agressor
    Rear: 29x2.5 WT / 3C / TR / EXO+ - Front: 27,5x 2.4 WT / 3C / TR / DD

  • Seat post

    KIND SHOCK LEV Integra
    34.9mm, 175mm travel

  • Saddle

    SDG Bel Air Steel
    145 mm, Fiber reinforced nylon Wing Flex

  • Weight

    15,6 kg / 34.39 lb
    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included

    No

  • Colour

    High Polished
    Shinny Finish

  • Accessories

    Down tube protector, chainstay protector, seatstay protector, FOX 38 fork fender

Bike specifications are subject to change without notice.

Technical informations

  • Bicycle type

    Enduro / Freeride

  • Frame material

    AL 6066 T4, T6

  • Frame weight

    3,9 kg / 8.59 lb

  • Rear travel

    160mm

  • Shock length/stroke

    230x62.5mm

  • Recommended SAG

    26-30% / 16-19mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    Included - 20x10mm

  • Recommended/max. fork height

    586mm / 596mm

  • Headset type

    ZS44 / ZS56

  • ICR compatible

    No

  • Wheels size

    29’’ - 27.5’’

  • Max. rear tyre dimension - ETRTO

    65mm - Ø584mm

  • rear brake mounting type

    Postmount 200mm

  • Rear brake rotor max. size

    220mm

  • Seatpost/seat clamp diameter

    34,9mm / 38,5mm

  • Seatpost insertion max.

    S : 228mm / M : 268mm / L : 288mm / XL : 308mm

  • Bottom bracket type

    Press Fit BB 92mm

  • Chain guide

    ISCG 05

  • Chain line

    55

  • Rear Hub dimension

    148x12mm

  • Rear Axle dimension

    Maxle standard, 180mm, M12, P1.75mm

  • UDH hanger

    No

  • shock anchor adjustment

    2 positions

Geometry

SIZE
SLow / High
MLow / High
LLow / High
XLLow / High
1 - SEAT TUBE LENGTH
380
420
440
460
2 - SEAT TUBE ANGLE
78° / 78,4°
78° / 78,4°
78° / 78,4°
78° / 78,4°
3 - HEAD TUBE ANGLE
63,6° / 64°
63,6° / 64°
63,6° / 64°
63,6° / 64°
4 - HEAD TUBE LENGTH
115
120
125
130
5 - WHEELBASE
1233 / 1232
1255 / 1254
1287 / 1286
1314 / 1313
6 - TOP TUBE LENGTH
570 / 569
591 / 590
617 / 616
644 / 643
7 - CHAIN STAY LENGTH
444 / 443
444 / 443
449 / 448
449 / 448
8 - BOTTOM BRACKET HEIGHT
4 / 0.1
4 / 0.1
4 / 0.1
4 / 0.1
9 - FORK LENGTH
586
586
586
586
10 - REACH
436 / 440
456 / 460
481 / 485
506 / 510
11 - STACK
633 / 630
637 / 634
642 / 639
647 / 643

All lengths in millimeters.

Size guide

What Size to Choose?

According to your riding style, choose a bike with a shorter Reach for more responsive and intuitive handling, or one with a longer Reach for more stability and confidence at high speeds. On a longer model, the front wheel is positioned farther forward, giving an enhanced feeling of security but at the expense of maneuverability and requiring more effort to move the bike.

Between Two Sizes?

When you find yourself between two sizes, the ideal solution is to test ride both to see which fits you best. Unfortunately, this isn't always possible. At minimum, check the Reach and Stack measurements of your current bike to compare them with those of the model you're considering. This will give you a better idea of which size to choose and how the position will feel once on the bike. You can also follow the advice below.

Morphology

Body proportions vary from person to person, even at identical heights. If you have long legs and a shorter-than-average torso, you might consider choosing a bike with a shorter Reach than the recommended size. Conversely, if you have long arms and a more developed upper body, the larger size might be better suited to your morphology. Ideally, you should try before you choose.

Suspension settings

Our kinematics are the result of advanced engineering for optimal working harmony of front and rear suspension with our bikes.

This guide is aimed to help understand exactly how things work and set everything up so that your COMMENCAL functions in the best way.
