COMMENCAL SUPREME DH V5 ROCKSHOX PURE WHITE image number null

COMMENCAL SUPREME DH V5 ROCKSHOX PURE WHITE

€ 5.416,66 excl. VAT
id/sku : BT4SUPV5RSEU1
Availability: Select the model for availability null
BUY IN-STORE
You can place your order and have the COMMENCAL product of your choice delivered directly to your nearest store. Your store will need to contact our B2B SALES DEPARTMENT to register your order. Your store receives the product and you will pay directly with them. The store will inform you of the receipt of your order.
10% off for pick-up in andorra
You can place your order online and have the COMMENCAL bikes, frames, skis and snowboards of your choice ready to collect directly from our SHOWROOM in Andorra. You will benefit from an additional 10% OFF the total price on our website (including VAT). Just contact our SALES DEPARTMENT to place an order. Our team will contact you to set a collection date shortly after the request is processed.
c
- DESCRIPTION -

CHECK OUT THE SUPREME DH V5

The SUPREME DH V5 is our pure race machine. It is the result of three years of work between our R&D department and our athletes. From the bike’s very first season racing World Cups, the results have been the best advertisement: 9 wins, 27 podiums and a first place in the Elite Women, Men and Team rankings.

With a concentrate of technologies and experience, the V5 inaugurates the High Virtual Contact System kinematics. This is our interpretation of the most efficient system for combining liveliness and shock absorption. Thanks to the inserts in the aluminium frame, the geometry and behaviour of the bike can be adapted to suit the conditions of the day.

SUPREME DH V5 SETTINGS GUIDE


COMMENCAL SUPREME DH V5 ROCKSHOX


The ROCKSHOX Boxxer Ultimate is a high-end downhill fork, equipped with the Charger 3 damper for precise adjustment (HSC, LSC, HSR, LSR). Designed for performance, it incorporates Electric Tall technology for increased stability and optimal control on the most demanding terrains.

The ROCKSHOX Vivid Coil Ultimate DH shock provides incomparable sensitivity and never heats up whatever the duration of the run or condition of the track.

Braking is managed by SRAM with a pair of Maven Bronze. The same as those used by Amaury Pierron when he’s racing World Cups. They are powerful, enduring, progressive, and precise.

DT SWISS wheels with F1900 Classic rims and hubs provide dynamism and reliability.

The SRAM GX DH transmission offers ultra-precise gear changes thanks to DH-specific staging.

Finally, the tyres come in the form of the SCHWALBE Tacky Chan with Super Downhill casing and Ultra Soft rubber. They were developed by the COMMENCAL MUC-OFF team to tackle the most demanding tracks on the circuit.

*Please note that bike specs may be subject to change without prior notice.

See more See less
- Video -
- TECHNICAL INFO -
  • Bicycle type

    Frame DH Racing

  • Frame material

    AL 6066 T4, T6

  • Frame weight

    5,3 kg / 11,68 lbs in size S with frame protections, chain guide, rear wheel axle

  • Rear travel

    220 mm

  • Shock length/stroke

    250 mm / 75 mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    30 x 8 mm / 30 x 8 mm

  • Recommended/max. fork height

    612 mm / 620 mm

  • Headset type

    ZS56 / ZS56

  • Maximum tyre dimension (etrto)

    65 mm

  • Disc brake standard

    Postmount 200 mm

  • Rear rotor max. size

    223 mm

  • Seatpost/seat clamp diameter

    31,6 mm / 34,9 mm

  • Bottom bracket type

    Press Fit BB 107

  • ISCG

    ISCG 05

  • Rear hub compatibility

    L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle

  • Flip Chip
    Front / Up
  • Wheel Base Length
    Centered
  • Bridge
    XS & S : Thin - M & L : Medium - XL : Thick
- SPECIFICATIONS -
  • Frame

    SUPREME DH V5 29/27, 220 mm travel
    27/29'', Alloy 6066, triple butted tubes, T4, T6.

  • Shock

    ROCKSHOX Vivid Coil Ultimate DH
    250 x 75 mm, HSC, LSC, LSR, rebound. Red Coil
    Spring rates: 400lbs on S, 450lbs on M, 500lbs on L, 550lbs on XL

  • Fork

    ROCKSHOX Boxxer Ultimate, 203 mm travel
    29'', Charger 3 damper, HSC, LSC, HSR, LSR, Boost (20 x 110 mm), 52 mm offset
    Electric Tall

  • Headset

    ACROS ZS56/ZS56
    Alloy cups, sealed bearings

  • Stem

    RIDE ALPHA DH
    40 mm extension, 31.8 mm

  • Handlebar

    RIDE ALPHA
    31.8 mm, 780 mm on S/M/L, 800 mm on XL, rise 27

  • Grips

    RIDE ALPHA Mushroom
    132 mm, single clamp, black

  • Brakes

    SRAM Maven Bronze, 4 pistons, sintered pads
    Rotors: SRAM HS2 220 mm, 6-bolts, 2.0 mm width

  • Shifters

    SRAM GX DH
    7s

  • Chain guide

    E13 LG1
    32-34t

  • REAR DERAILLEUR

    SRAM GX Eagle
    7s

  • Bottom bracket

    SRAM DUB
    Pressfit

  • Crankset

    SRAM Descendant DH, 165 mm crank arms, DUB
    Chainring: SRAM Descendant DH, 34t

  • Chain

    SRAM PC-1130
    11s

  • Cassette

    SRAM PG-720 DH
    7s, 11-25t

  • Rims

    DT SWISS F1900 Classic
    Rear: 27.5'', 32h, 30 mm inner width, 12 x 157 mm - Front: 29'', 32h, 30 mm inner width, 20 x 110 mm

  • Hubs

    Included with wheelset

  • Spokes/nipples

    Included with wheelset

  • Tyres

    Rear: SCHWALBE Tacky Chan - Front: SCHWALBE Magic Mary
    Rear: 27.5''x2.4'', Super DH, Addix Ultra Soft, Tubeless Easy - Front: 29''x2.4", Super DH, Addix Ultra Soft, Tubeless Easy

  • Seat post

    RIDE ALPHA
    31.6 mm, 250 mm

  • Saddle

    FIZIK Gravita Alpaca X5
    130 mm width, S-Alloy rails, Team edition

  • Weight

    18,7 kgs - 41,22 lbs
    Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included

    No

  • Colour

    Pure White
    Shiny Finish

  • Accessories

    Chainstay protector, seatstay protector, fork bumpers, downtube protector, Fox 40 fender
    *Please note that bike specs are subject to change without prior notice

- SIZES -
- GEOMETRY -
SIZES
