- DESCRIPTION -

CHECK OUT THE SUPREME DH V5

The SUPREME DH V5 is built for one thing: winning. It’s the result of three years of collaboration between our R&D team and top athletes. From its very first World Cup season, the results spoke for themselves: 9 wins, 27 podiums, and first place in the Elite Women’s, Men’s and Team rankings.

Packed with advanced tech and experience, the V5 introduces our High Virtual Contact System kinematics. It’s our take on the most efficient way to combine reactivity and big-hit absorption. With inserts built into the aluminium frame, geometry and ride characteristics can be fine-tuned to match the day’s conditions.

SUPREME DH V5 SETTINGS GUIDE

Frame not compatible with the new FOX Float X2 2026 shock.

See more See less
- TECHNICAL INFO -
  • Bicycle type

    Frame DH Racing

  • Frame material

    AL 6066 T4, T6

  • Frame weight

    5,4 kg / 11,9 lbs in size S with frame protections, chain guide, rear wheel axle

  • Rear travel

    220 mm

  • Shock length/stroke

    250 mm / 75 mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    30 x 8 mm / 30 x 8 mm

  • Recommended/max. fork height

    612 mm / 620 mm

  • Headset type

    ZS56 / ZS56

  • Maximum tyre dimension (etrto)

    65 mm

  • Disc brake standard

    Postmount 200 mm

  • Rear rotor max. size

    223 mm

  • Seatpost/seat clamp diameter

    31,6 mm / 34,9 mm

  • Bottom bracket type

    Press Fit BB 107

  • ISCG

    ISCG 05

  • Rear hub compatibility

    L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle

  • Accessories

    Down tube protector, chainstay protector, seatstay protector, rear wheel axle, chainguide, frame mudguard, roller cover, rear brake adaptor, rear hanger

  • Flip Chip
    Front / Up - Rear / Low (Available as an option: Front / Low - Rear / Up)
  • Hub Old
    157 x 12
  • Wheel Base Length
    Centered (Available as an option: Flip Flop +/-6mm)
  • Bridge
    XS & S: Thin - M & L: Medium - XL: Thick (All bridges are available as an option)
- SPECIFICATIONS -
  • Colour

    Glittery White - Shiny Finish

- SIZES -
- GEOMETRY -
SIZES
