COMMENCAL META POWER TR SHIMANO RACE BRUSHED
- TECHNICAL INFO
- TECHNICAL SPECIFICATIONS
- Size Chart
The META POWER TR is designed for the ride. With 140mm of travel it's easy to tame and is forgiving to the rider. Dynamic and playful, it ensures effective pedalling thanks to excellent geometry. The straightened seat tube and long front-end ideally positions the rider between the two wheel axles. The 29-inch wheels allow you to tackle the most technical climbs. This is the bike for those who like long rides and enjoying letting go of the brakes on the downhill.
META POWER TR RACE
Our META POWER TR RACE was immediately popular with this shiny Brushed finish.
And what about the complimentary ROCKSHOX red colours with it? The suspension combo is top-of-the-range, consistent with what we wanted from this bike.
- The famous ROCKSHOX Lyrik Ultimate has demonstrated quality in numerous Enduro World Series races in recent years. It is perfect for EMTB use.
- The Super Deluxe Ultimate Coil will delight the most demanding riders thanks to its sensitivity, flawless and unwavering behaviour whatever the terrain or weather.
Ultra-efficient, this META POWER TR RACE features excellent stopping power with the TRP DH-R Evo 4 pistons brakes, to ensure powerful and consistent braking in all circumstances. The SRAM GX Eagle 10-52t drivetrain has proved its reliability over many years. The DT SWISS HX1700 Spline EMTB-specific wheels complete this high-end build which is perfect for big trips in the mountains. Finally, the SHIMANO EP8 engine with 630WH battery powers this POWER.
This pot of top components make the META POWER TR RACE a formidable weapon on any type of trail.
*Please note that bike specs are subject to change without prior notice.
E-BIKE TRAIL 29''
AL-6061 + AL-6066
4,1 kg / 9.03 lb - With plastic accessories.
210 x 55 mm
Piggy back shock compatible
20 x 10 mm / NOTHING
Recommended/max. fork height
566 mm / 576 mm
ZS56 / ZS66
Maximum tyre dimension (etrto)
65 mm - 622
Disc brake standard
Rear rotor max. size
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
Yes (SHIMANO Standard)
Rear hub compatibility
12 x 148 mm
2022 META POWER TR, 140 mm
29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
Max. torque: 85N.m, 250W
LCD colored display featuring: Clock, Assist mode display, Battery charge level, Current Speed, Maximum speed, Average speed, Trip distance, Trip time, Estimated range, Range overview, Cadence, Human output power (as scale indicator), Calorie setting, Maintenance alert, Bluetooth LE connection (for E-Tube Project communication)
ROCKSHOX Super Deluxe Coil Ultimate
210 x 55 mm, LSC, rebound, 2-position adjustment. 210 x 55 mm, LSC, rebound, 2-position adjustment. Spring rate 350 LBS on S and M / 400 LBS on L / 450 LBS on XL
ROCKSHOX Lyrik Ultimate, 150 mm travel
29", Charger 2.1 damper, Debonair, LSC, HSC, rebound, Boost (15 x 110 mm), 42 mm offset, 2 Tokens
ACROS ZS56 / ZS66
Alloy cups, sealed bearings
RIDE ALPHA Freeride 40
40 mm extension, 31,8 mm
RIDE ALPHA R20 POWER on S - RIDE ALPHA R27 POWER on M / L / XL
Internal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
ODI Elite Motion
Soft pro compound, single clamp, black
TRP DH-R Evo
SRAM GX Eagle
12s, Single Click
RIDE ALPHA EP8
SRAM GX Eagle
E13 E*Spec Plus EP
32t, Narrow-Wide, direct mount
SRAM GX Eagle
SRAM GX Eagle
Rear: DT SWISS HX1700 Spline - Front: DT SWISS HX1700 Spline
Rear: 29'', 28h, welded, 30 mm inner width - Front: 29'', 28h, sleeved, 30 mm inner width
Rear: DT SWISS 350 - Front: DT SWISS 350
Rear: 28h, sealed bearings, e-bike specific - Front: 28h, sealed bearings
DT SWISS Hybrid 1
Straightpull, 2.34/2.0mm, double butted, stainless, with Nylok, black
Rear: SCHWALBE Nobby Nic - Front: SCHWALBE Magic Mary
Rear: 29"x2.4", Super Trail, Addix SpeedGrip, Tubeless Easy - Front: 29"x2.4", Super Trail, Addix Soft, Tubeless Easy
KS Lev Integra
31.6 mm, travel: 125 mm on S, 175 mm on M/L, 200 mm on XL, SouthPaw alloy remote
FIZIK Terra Aidon X3
Kium Mobius rails
24,8 kg / 54.67 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
RIDE ALPHA CNC pedals, motor protector, chainstay protector, seatstay protector, user manual
META POWER bikes are delivered with Shimano Europlug (CEE 7/7 norm) battery charger, a plug adapter is necessary for customers living in countries using different standards.
Partnership with SHIMANO
In partnership with SHIMANO, COMMENCAL supports a voluntary battery recycling program for ebike batteries. For each META POWER sold COMMENCAL will contribute 7EUR to fundraising organisation COREPILE. This sum is paid through SHIMANO France. When your battery reaches the end of its life, it would be great if you could send it back to us for recycling.
