- DESCRIPTION -

The SUPREME DH V5 SIGNATURE delivers top-tier performance for serious downhill riders, built with precision FOX Factory suspension.

• Experience unmatched control with the FOX 40 Factory fork and its Grip X2 cartridge, offering versatile adjustments to conquer every trail with confidence. The FOX DHX2 Factory shock with four adjustment circuits ensures exceptional support and smooth absorption for ultimate comfort.
• Reliable stopping power comes from SRAM Maven Silver 4-piston brakes paired with 223mm discs, providing consistent, responsive braking in every condition.
• Wheels combine DT SWISS FR541 front and FR571 rear rims, hand-built on 350 hubs, designed specifically for the demands of gravity riding.
• The SRAM GX DH 7-speed drivetrain delivers precise, rapid shifting for downhill precision and reliability, keeping you in control at all times.

See more See less

- Video -

- TECHNICAL INFO -

Bicycle type
Frame DH Racing
Frame material
AL 6066 T4, T6
Frame weight
5,3 kg / 11,68 lbs in size S with frame protections, chain guide, rear wheel axle
Rear travel
220 mm
Shock length/stroke
250 mm / 75 mm
Piggy back shock compatible
Yes
Shock bushings
30 x 8 mm / 30 x 8 mm
Recommended/max. fork height
612 mm / 620 mm
Headset type
ZS56 / ZS56
Maximum tyre dimension (etrto)
65 mm
Disc brake standard
Postmount 200 mm
Rear rotor max. size
223 mm
Seatpost/seat clamp diameter
31,6 mm / 34,9 mm
Bottom bracket type
Press Fit BB 107
ISCG
ISCG 05
Rear hub compatibility
L=200 mm, M12, P1.0 mm - Hub 157 x 12 mm standard Maxle
Flip Chip
Front / Up
Wheel Base Length
Centered
Bridge
XS & S : Thin - M & L : Medium - XL : Thick

- SPECIFICATIONS -

Frame
SUPREME DH V5, 220 mm travel
29/27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
Shock
FOX DHX2 Factory
250 x 75 mm, HSC, LSC, HSR, LSR
425lbs on S, 475lbs on M, 525lbs on L, 575lbs on XL
Fork
FOX 40 Factory, 200 mm
29", Grip X2, HSR, LSR, HSC, LSC, Boost (20 x 110 mm), 52 mm offset
Headset
ACROS ZS56/ZS56
Alloy cups, sealed bearings
Stem
BURGTEC MK3 DH
45 mm extension, direct mount, 31.8 mm
Handlebar
BURGTEC Ride Wide
31.8 mm, 800 mm width, 30 mm rise, Alloy 6061
Grips
ODI Longneck V2.1
Single clamp, black
Brakes
SRAM Maven Silver, 4 pistons, resin pads
Rotors: SRAM HS2 220 mm, 6-bolt, 2.0 mm thickness
Shifters
SRAM GX DH
7s
Chain guide
E13 LG1
32-34t
REAR DERAILLEUR
SRAM GX DH
7s
Bottom bracket
SRAM DUB
Pressfit
Crankset
SRAM Descendant DH, 165 mm crank arms, DUB
Chainring: SRAM Descendant DH, 34t
Chain
SRAM PC-1110
11s
Cassette
SRAM PG-720 DH
7s, 11-25t
Rims
Rear: DT SWISS FR571 - Front: DT SWISS FR541
Rear: 27.5'', 32h, 30 mm inner width - Front: 29'', 32h, 30 mm inner width
Hubs
DT SWISS 350
Rear: 32h, sealed bearings, 12 x 157 mm, SHIMANO Hyperglide - Front: 32h, sealed bearings, 20 x 110 mm
Spokes/nipples
DT SWISS Competition
Straightpull
Tyres
Rear: MAXXIS Minion DHR II - Front: MAXXIS High Roller III
Rear: 27.5x2.50WT 3C MaxxTerra / DH Casing / TR - Front: 29x2.50WT 3C MaxxGrip / DH Casing / TR
Seat post
RIDE ALPHA
31.6 mm, 250 mm length
Saddle
FIZIK Gravita Alpaca X5
S-Alloy rails, Team edition
Weight
- kg / - lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
No
Colour
Pure White
Shiny Finish
Accessories
Down tube protector, chainstay protector, seatstay protector, shuttle pad, fork bumpers, FOX 40 fender
