COMMENCAL META SX V4 SIGNATURE CHAMPAGNE
- TECHNICAL INFO
- TECHNICAL SPECIFICATIONS
- Size Chart
ALL ABOUT META SX V4
The META SX V4 is made to engage and go fast. It features a generous wheelbase, reworked frame and kinematics for its 29/27.5-inch wheels, and perfectly combines stability with liveliness. This is the mountain bike we all need for riding the steepest, most technical terrain and holding lines like no other. Enduro trails or motorway sections in the bike park; it can do it all!
META TR V4 - META SX V4: WHICH ONE TO CHOOSE?
META SX V4 SIGNATURE CHAMPAGNE
The META SX V4 SIGNATURE is our most advanced version of the META SX V4. All components are chosen to exploit the quintessence of this frame.
The FOX 38 Factory fork is a must. The rigid chassis provides comfort through rough sections and precision through turns. There are numerous adjustments to perfectly adapt it to your style, without forgetting the decompression valves for constant performance.
The FOX Float X2 Factory shock comes from racing. The large air volume gives it the linearity and feel of a coil spring. With four ways of hydraulic adjustment and the ability to change air volume and pressure, everything is covered.
SHIMANO manages the gear changes and braking with the Deore XT groupset. 12-speed drivetrain, 4-piston calipers and 203mm discs: for more than 40 years it has been a reference point in the market.
DT SWISS custom wheels are specifically designed for this bike. They consist of one of the best enduro rims on the market, the EX 511, combined with reliable and solid 350 hubs.
It is the combo of SCHWALBE Magic Mary and Big Betty tyres in Addix Soft rubber that will ensure the grip.
*Please note that bike specs are subject to change without prior notice.
AL-6066 T4, T6
3,9 kg / 8.59 lb
230 x 62,5 mm
Piggy back shock compatible
Nothing on body - 20 x 10 mm on shaft
Recommended/max. fork height
586 mm / 596 mm
TAPERED 1-1/8" / 1-1/2"
ZS44 / ZS56
Maximum tyre dimension (etrto)
68-584 mm - 29'' : 65-622 mm
Disc brake standard
POSTMOUNT 200 mm
Rear rotor max. size
Seatpost/seat clamp diameter
34,9 mm / 38,5 mm
Bottom bracket type
Rear hub compatibility
L=180 mm, M12, P1.75 mm - Hub 12 X 148 mm standard maxle
META SX, 160 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
FOX Float X2 Factory
230 x 62.5 mm, HSC, LSC, HSR, LSR, 2-postion adjustment
FOX 38 Factory, 170 mm travel
29", Grip 2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 44 mm offset, 2 Tokens
Alloy cups, sealed bearings
RIDE ALPHA Freeride 40
40 mm extension, 31,8 mm
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
ODI Elite Motion
Soft pro compound, single clamp, black
SHIMANO XT, 4 pistons, I-Spec EV compatible
Rotors: SHIMANO SM-RT86 203 mm, 6 holes
SHIMANO XT, 170 mm crank arms, Boost
Chainring: SHIMANO XT, 32t, Dynamic Chain Engagement + Technology
Rear: DT SWISS EX511 27.5'' - Front: DT SWISS EX511 29''
Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
Rear: DT SWISS 350 - Front: DT SWISS 350
Rear: 28h, sealed bearings, 12 x 148 mm, MicroSpline, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black
DT SWISS Competition
Straightpull, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black
Rear: SCHWALBE Big Betty - Front: SCHWALBE Magic Mary
Rear: 27.5" x 2.4", Super Trail, Addix Soft, Tubeless Easy - Front: 29" x 2.4", Super Trail, Addix Soft, Tubeless Easy
FOX Transfer Factory
31.6 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L and 200 mm on XL, 1x lever + seat tube adaptor to 34.9 mm
FIZIK Terra Alpaca X5
145 mm width, S-alloy rails
15,9 kg / 35.05 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Down tube protector, chainstay protector, seatstay protector, FOX 38 Fender
*Please note that bike specs are subject to change without prior notice
