- DESCRIPTION -

To own a CLASH is to feel like part of a team. Whether it's the adult version or the Kids model, the CLASH is playful and lively, and made with care by us. With 3 years of good and loyal service, it was important timing to overhaul the CLASH Kids. Everything is new and beautiful - new kinematics perfectly suited to kids, top-of-the-range parts and all with exceptional handling.

''I'm Faster than Dad'' becomes the rallying cry!

The range is made up of three platforms with different wheel sizes: 20, 24 and 26 inches (JR).

We are continuously committed to improving our bikes. In order to continue to strive for better, more upmarket bikes, we use our previous platforms to determine specific points of improvement.

Now based on an all-new chassis, the CLASH Kids uses a virtual pivot point (VPP) kinematic designed to provide liveliness, sensitivity and comfort to the lightest riders. The CLASH 20/24/JR and XS also have a specific series of tubes adapted to the weight of the riders. The idea is to improve various points:
- Largely lighter frames with reduced tube profiles.
- Rigidity and flexibility of the frame balanced better for children's weights.
- Reduced bearing sizes for more sensitivity.
- A completely reworked look.

In terms of suspension, the CLASH 20 and 24 have a MANITOU Junit Pro fork with 120 and 145mm of travel respectively. Designed in partnership with our brand, this fork is particularly well suited to these bikes and for children thanks to:
- A specific hydraulic spring which effectively manages rebound and considerably reduces friction.
- A new pneumatic spring which means all the travel of the fork is used despite the low weight of the child.
- Specific seals reduce friction and increase performance and comfort.
- Aluminium knobs and a 'Gloss Black' finish that give it a high-end appearance.

As for the components of these two models, they feature a PROTAPER handlebar and grips that have been developed for little hands as well as a crankset and cranks suitable for shorter legs. We see the arrival of 180mm disc brakes for more performance and reliability, and the shock fixings are now mounted using bearings to provide more sensitivity.

The CLASH JR frame itself has also been extensively revised. Smaller than the 2021 version with a largely shortened top tube, it also moves down a wheel size from 27.5 to 26-inch. With the arrival of the new XS range, this makes perfect sense. The size differences between each bike are therefore much smaller and the CLASH JR is becoming a serious option for young adolescents who are still a way off moving up to the big wheels. Whilst these components are like those found on our adult models, including the introduction of new FOX Performance suspension, the frame and kinematics have been specifically designed for smaller sized people.

*Please note that bike specs are subject to change without prior notice.

See more See less
- TECHNICAL INFO -
  • Bicycle type

    ENDURO - FREERIDE KIDS 24

  • Frame material

    AL-6061 + AL-6066

  • Frame weight

    2,9 kg / 6.39 lb

  • Rear travel

    145 mm

  • Shock length/stroke

    190 x 45 mm

  • Piggy back shock compatible

    Yes

  • Shock bushings

    20 x 8 mm Front, 30 x 8 mm + Bearings on shock head

  • Recommended/max. fork height

    500 mm - 510 mm

  • Headset dimension

    -

  • Headset type

    ZS44 / ZS56

  • Maximum tyre dimension (etrto)

    24 x 2,5"

  • Disc brake standard

    Post Mount 180 mm

  • Rear rotor max. size

    200 mm

  • Seatpost/seat clamp diameter

    31,6 mm - 34,9 mm

  • Bottom bracket type

    PF 92 mm

  • ISCG

    ISCG05

  • Rear hub compatibility

    12 x 148 mm

- SPECIFICATIONS -
  • Frame

    2022 CLASH 24, 145 mm travel

    24", Alloy 6066, triple butted tubes, T4, T6. Enduro bearings

  • Shock

    ROCKSHOX Deluxe Select

    190 x 45 mm, rebound, 3 tokens

  • Fork

    MANITOU Machete Junit Pro, 145 mm travel

    24'', kids specific air cartridge, rebound, compression. Custom tuned for Commencal Bicycles. Boost (15 x 110 mm)

  • Headset

    ACROS ZS44 / ZS56

    Alloy cups, sealed bearings

  • Stem

    RIDE ALPHA Freeride 40

    40 mm extension, 31,8 mm

  • Handlebar

    PROTAPER Junit Rizer bar

    31.8 mm, 680 mm width, 25 mm rise, Alloy 7050-T76, Stealth

  • Grips

    PROTAPER Junit 27 mm

    Kids specific 27 mm diameter

  • Brakes

    SHIMANO Deore, I-Spec EV compatible

    Rotors: SHIMANO SM-RT66 180 mm, 6-bolt

  • Shifters

    SRAM NX

    11s

  • Chain guide

    -

  • Rear mech

    SRAM NX

    11s

  • Bottom bracket

    AEROZINE PressFit BB92 / 41 mm outside diameter for 30 mm spindle

  • Crankset

    AEROZINE Xeon-A1, 145 mm crank arms, 30 mm axle, 7075 alloy

    Chainring: AEROZINE Direct Mount 32t, Narrow-Wide, full CNC

  • Chain

    KMC X11

    11s

  • Cassette

    SRAM PG-1130

    11-42t

  • Rims

    SPANK Spoon 28

    24", 28h, 23 mm inner width

  • Hubs

    Rear: FORMULA DC-348A - Front: FORMULA DC-711

    Rear: 28h, sealed bearings - Front: 28h, sealed bearings

  • Spokes/nipples

    SAPIM D-Light

    J-Bend, 2.0-1.6-2.0mm, double butted, stainless, with Nylok, black

  • Tyres

    Rear: SCHWALBE Big Betty - Front: SCHWALBE Big Betty

    Rear: 24" x 2.25", Super Trail, Addix Soft - Front: 24" x 2.25", Super Trail, Addix Soft

  • Seat post

    KS Rage-I

    31,6 mm, 75 mm travel, SouthPaw alloy remote

  • Saddle

    SDG Fly Jr

    Kids specific, reinforced sides

  • Weight

    12,5 kg / 27.55 lb

    without pedals. Weight may differ slightly due to manufacturing tolerances.

  • Pedals included

    No

  • Colour

    Champagne

    Matte Finish

  • Accessories

    Down tube protector, chainstay protector, seatstay protector

- SIZES -
- GEOMETRY -
