The META HT Kids range features real enduro mountain bikes designed for young people. They love adventuring off the beaten track and may also be particularly comfortable on a pump track or on the streets.
The range consists of three models with different wheel sizes; 20-inch, 24-inch and 27.5-inch (JR).
But forget wheel size for a minute, because all of the META HT Kids range showcase high-end frames. The series of tubes are specifically designed to offer comfort and liveliness. The rear triangle tubes are worked to generate a vertical flex and therefore ensure comfort. All three models are equipped with a telescopic fork which reduces friction as much as possible so that the travel is used to the full, even during small impacts and for smaller, lighter humans. The comfort and grip are exceptional for a bike of this size. What a way to spend their days on a bike!
META HT 24
On the META HT 24, the frame is semi-rigid with a 120mm telescopic fork. This fork was specifically developed by our engineers in collaboration with MANITOU. The main objective is to reduce friction as much as possible so that the travel is used to the full, even during small impacts and for smaller, lighter humans. The comfort and grip are exceptional for a bike of this size.
*Please note that bike specs are subject to change without prior notice.
Bicycle type
ALL MOUNTAIN HARDTAIL 24
Frame material
Al 6061 T6
Recommended/max. fork height
470 mm - 480 mm
Headset dimension
TAPERED 1-1/8 / 1-1/2
Headset type
ZS44 / ZS56
Maximum tyre dimension (etrto)
63 mm
Disc brake standard
IS 160 mm
Rear rotor max. size
180 mm
Seatpost/seat clamp diameter
31,6 mm - 34,9 mm
Bottom bracket type
BSA 68 mm
ISCG
No
Rear hub compatibility
135 x 9 mm
Frame
2021 Meta HT 24
Alloy 6061, triple butted tubes, T4, T6.
Fork
MANITOU Machete Junit Pro, 120 mm travel
24, kids specific air cartridge, rebound, compression. Custom tuned for Commencal Bicycles. Boost (15 x 110 mm)
Headset
ACROS ZS44 / ZS56
Alloy cups, sealed bearings
Stem
RIDE ALPHA Freeride 40 mm
40 mm extension, 31,8 mm
Handlebar
PROTAPER Junit Rizer bar
31,8 mm, 600 mm width, 25 mm rise, Alloy 7050-T76, Stealth
Grips
PROTAPER Junit 27 mm
Kids specific 27 mm diameter
Brakes
SHIMANO MT-200, hydraulique disc brake
Rotors: LEGION 180 / 180 mm
Shifters
SRAM NX
11s
Rear mech
SRAM NX
11s
Bottom bracket
AEROZINE BSA 30
Threaded
Crankset
AEROZINE Xeon-A1, 145 mm crank arms, 30 mm axle, 7075 alloy
Chainring: AEROZINE Direct Mount 32t, Narrow-Wide, full CNC
Chain
KMC X11
11s
Cassette
SRAM PG-1130
11s, 11-42t
Rims
ALEXRIMS MD30
24, 32h, 30 mm inner width
Hubs
Rear: FORMULA RX-26 - Front: FORMULA DC-711
Rear: 32h, sealed bearings, Front: 32h, sealed bearings
Spokes/nipples
SAPIM Leader
J-Bend 2.0 mm, stainless, with Nylok, black
Tyres
Rear: VEE TIRE CO. Crown Gem - Front: VEE TIRE CO. Crown Gem
Rear: 24'' x 2.6'', MPC compound / Skinwall, Wire bead, 27 TPI - Front: 24'' x 2.6'', TMPC compound / Skinwall, Wire bead, 27 TPI
Seat post
KS Rage-I
31,6 mm, travel: 75 mm, SouthPaw alloy remote
Saddle
SDG Fly Jr
Kids specific, reinforced sides
Weight
12,1 kg / 26.67 lb
Without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
Yes
Colour
Dirt
Matte finish
Accessories
Small pedals, chainstay protector, seatstay protector
