COMMENCAL CLASH ORIGIN HERITAGE GREEN
- TECHNICAL INFO
- TECHNICAL SPECIFICATIONS
- Size Chart
The CLASH has 170 mm of travel and 27.5" wheels, and is designed for one thing and one thing only - having fun! With a look of the FRS, the freeride affiliation is obvious. In addition to descending at full gas, the CLASH knows how to pedal to get to the trailhead when the lift is closed. Depending on the terrain you can optimise grip or dynamism thanks to a specific insert.
CLASH ORIGIN HERITAGE GREEN
Offered in this Heritage Green Matte finish, the CLASH ORIGIN is modern and classy. It goes perfectly with its Full Black components.
On the component side, we have prioritized reliability and ease of use:
- The SRAM SX 12-speed transmission, with a wide 11-50t ratio, is as reliable as high performance.
- The 4-piston SRAM Guide T brakes are equipped with 200mm discs, to be able to brake hard and sustainably.
As for the suspensions, the manufacturer ROCKSHOX is in charge:
- At the front, a Domain R fork, rigid and precise thanks to its 38mm plungers.
- At the rear, a Deluxe Select shock absorber which is very easy to adjust.
With these suspensions, comfort and grip are assured, both uphill and downhill. All the details have been worked out.
*Please note that bike specs are subject to change without prior notice.
ENDURO / FREERIDE
AL 6066 T4, T6
4 kg / 8.81 lb
Adjustable via flip chip: 170 mm on Grip position / 155 mm on Dynamic position
230 mm x 65 mm
Piggy back shock compatible
20 x 8 mm on body - 30 x 10 mm on shaft
Recommended/max. fork height
572 mm / 586 mm
ZS44 / ZS56
Maximum tyre dimension (etrto)
27,5" - 65 mm
Disc brake standard
Postmount 200 mm
Rear rotor max. size
Seatpost/seat clamp diameter
34,9 mm / 38,5 mm
Bottom bracket type
Press Fit BB 92
Rear hub compatibility
L=180 mm, M12, P1.75 mm - moyeu 148 x 12 mm standard maxle
CLASH, 170 mm travel
27.5'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
ROCKSHOX Deluxe Select +
230 x 65 mm, RT damper, DebonAir Linear, rebound, 2 pos comp
ROCKSHOX Domain R, 180 mm travel
27.5", DebonAir, external rebound, Boost (15 x 110 mm), 44 mm offset, 0 Token
Alloy cups, sealed bearings
RIDE ALPHA Freeride 40
40 mm extension, 31.8 mm
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
RIDE ALPHA DH
Ultra-soft compound, single clamp, black
SRAM Guide T, 4 pistons, MatchMaker compatible
Rotors: SRAM G2 CleanSweep 200 mm, 6-bolt
SRAM SX Eagle
SRAM SX Eagle
SRAM X1 1000 Eagle, 170 mm crank arms, DUB, Boost
Chainring: SRAM X1 1000 Eagle, 34t, Narrow-Wide
SRAM NX Eagle
E13 LG1 DH Base
27.5'', 32h, 30 mm inner width
Rear: FORMULA DCL-348A - Front: FORMULA DC-711
Rear: 32h, 12 x 148 mm, sealed bearings, Shimano Hyperglide - Front: 32h, 15 x 110 mm, sealed bearings
J-Bend, 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black
Rear: MAXXIS DHR II - Front: MAXXIS Assegai
Rear: 27.5" x 2.4", WT, 3C MaxxTerra, EXO+, Tubeless Ready - Front: 27.5" x 2.5", WT, 3C MaxxGrip, EXO+, Tubeless Ready
34.9 mm, 400 mm on S/M, 450 mm on L/X
SDG Bel Air V3
140 mm width, Steel Rails
15,5 kg / 34.17 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Down tube protector, chainstay protector, seatstay protector, shuttle pad
